NMAX160A Nmax160Ase: (BNN1) (BNN2)

NMAX160A ( BNN1 )
BRASIL
NMAX160ASE ( BNN2 ) BRASIL
1YBNN-280P1
( )
NMAX160A
CATÁLOGO DE PEÇAS
©2022, Yamaha Motor do Brasil Ltda.
1a edição, Novembro 2022
Todos os direitos reservados.
É proibida expressamente toda e qualquer
reimpressão ou utilização sem a autorização
por escrita da
Yamaha Motor do Brasil Ltda.
Impresso no Brasil.
PREFÁCIO
Este Catálogo de Peças se refere as Peças dos modelos relacionados na capa. Quando for 6. O asterisco (*) antes do Número de referência da peça indica a modificação ocorrida
solicitar peças de reposição para estes Modelos, recorra a este Catálogo de Peças e especifi- após a primeira edição.
que corretamente os códigos e Nomes das Peças.
1. As Modificações ou adições que tenham sido efetuadas após a publicação deste Catá-
logo de Peças, serão comunicadas a Rede de Concessionárias através das informa-
ções de Modificação de Peças (Parts News).
2. Abreviaturas
Seguem abaixo as abreviaturas utilizadas neste Catálogo de Peças:
“UR” Uso Restrito para o Código da Peça
“UN” Uso Necessário
“AP” Peça Alternativa
“LM” Fabricação Local (A peça pode ser pedida localmente)
“F#” No. de Série do Chassi (Aplicação do Número de Série)
“O/S” Tamanho Maior
3. Peças componentes de conjuntos

• As peças que são fornecidas dentro de conjuntos estão listadas com um ponto de
identificação (.)como segue abaixo.
• O número que aparece a direita da descrição da Peça indica o número de Peças
usado em cada Conjunto Individual.
No. PEÇA DESCRIÇÃO QTDE OBSERVAÇÕES

2F5–83310–60 PISCA DIANTEIRO CONJ. 2
115–83311–60 .LÂMPADA (6V–18W) 1
4. Os gráficos que são Aplicados em Peças Coloridas estão representados na coluna “OB-
SERVAÇÕES”, como segue abaixo.
No. PEÇA DESCRIÇÃO QTDE OBSERVAÇÕES

TANQUE DE COMBUSTÍVEL
2N4–24110–00–X5 2 MXR
COMPL.
3J1–24240–10 .GRÁFICO, TANQUE DE COMB. 1 PARA MXR
5. Observe que as ilustrações são referentes apenas a indicação dos códigos das peças, e
não para montagem. Para montagem, por favor utilize o Manual de Montagem apropria-
do.
PREFÁCIO
7. Aplicação do Número de Série 9. Aplicação do No. de Série Inicial
No. de Série do Chassi No. de Série do Motor No. de Série do Chassi
No. Série Nome do Modelo Código do Modelo

9C6SG5920P0000101 NMAX160A BNN1
9C6SG5920P0000141 NMAX160ASE BNN2
No. de Série do Motor
No. Série Nome do Modelo Código do Modelo

8. Aplicação do Código de Cor (A marca (*) mostra a cor do Modelo.)
G3M2E-038523 NMAX160A BNN1
G3M2E-038563 NMAX160ASE BNN2
Abreviação Nome da Cor Código da Cor
DPBMU(*) DARK PURPLISH BLUE METALLIC U 0996
MBL2 MAT BLACK 2 0582
MDBNM4(*) MAT DARK BLUISH GRAY ME 4 1847
MNM3(*) MAT GRAY METALLIC 3 1278
MNYM3 MAT GRAYISH YELLOW METALLIC 3 1831
RSH(*) RED SOLID H 1725
SMX BLACK METALLIC X 0903
YB YAMAHA BLACK 0033
ÍNDICE GERAL
MOTOR
CILINDRO...............................................................................1 SISTEMA ELETRICO 3.......................................................... 54
VIRABREQUIM E PISTAO..................................................... 3 ÍNDICE GERAL
VALVULA................................................................................4
CORRENTE DO EIXO DE COMANDO..................................5 ÍNDICE NUMÉRICO............................................................... 55
BOMBA DE AGUA..................................................................6
RADIADOR E MANGUEIRAS................................................ 7
BOMBA DE OLEO..................................................................9
ADMISSAO.............................................................................10
ESCAPAMENTO.................................................................... 12
CARCACA DO MOTOR......................................................... 13
TAMPA DA CARCACA 1........................................................15
EMBREAGEM........................................................................ 16
TRANSMISSAO......................................................................18
CHASSI
CHASSI.................................................................................. 19
PARA-LAMA........................................................................... 21
TAMPA LATERAL.................................................................. 22
GARFO TRASEIRO. SUSPENSAO 1.................................... 24
GARFO DIANTEIRO.............................................................. 25
TANQUE DE COMBUSTIVEL................................................ 27
ASSENTO...............................................................................28
RODA DIANTEIRA 1.............................................................. 30
PINCA DE FREIO DIANTEIRA...............................................31
RODA TRASEIRA 1............................................................... 32
PINCA DE FREIO TRASEIRA................................................33
GUIDAO E CABOS.................................................................34
CILINDRO MESTRE DIANTEIRO.......................................... 36
CAVALETE. ESTRIBOS. PEDAL........................................... 38
PROTETOR DE PERNA........................................................ 41
PARABRISA........................................................................... 44
GERADOR..............................................................................45
PISCAS 1................................................................................46
MEDIDOR...............................................................................47
FAROL DIANTEIRO............................................................... 48
LANTERNA TRASEIRA..........................................................49
INTERRUP. DO GUIDAO E MANETE 1................................ 50
SISTEMA ELETRICO 1.......................................................... 51
SISTEMA ELETRICO 2.......................................................... 53
FIG. 1 CILINDRO
REF.
BNN1
BNN2
No. PEÇA DESCRIÇÃO OBSERVAÇÕES
NO.
1 BBB–E1102–00 CABECOTE DO CILINDRO CONJ. 1 1
2 2DP–E1133–10 .GUIA DA VALVULA 1 4 4
3 90340–12813 .TAMPAO DO DRENO 1 1
4 95E32–06010 PARAFUSO FLANGE 1 1
5 90430–06803 GAXETA 1 1
6 95612–08618 PRISIONEIRO 2 2
7 2DP–E1191–00 TAMPA, CABECOTE DO CILINDRO 1 1 1
8 B3V–E1165–00 PLACA DE RESPIRO 1 1
9 2DP–E1169–00 GAXETA DA TAMPA DO RESPIRO 1 1
10 90149–05801 PARAFUSO 4 4
12 99530–08012 PINO GUIA 2 2
13 2DP–E132G–00 HASTE 1 1 1
14 93102–08800 RETENTOR DE OLEO 1 1
15 B3F–E1193–00 GAXETA DA TAMPA DO CABECOTE 1 1 1
16 90170–08810 PORCA 4 4
17 90201–08859 ARRUELA PLANA 4 4
18 2DP–E1391–00 PRISIONEIRO 2 2
19 2DP–E1392–00 PRISIONEIRO 2 2 2
20 94700–00415 VELA DE IGNICAO (NGK CPR8EA) 1 1
21 2DP–E1181–00 GAXETA, CABECOTE DO CILINDRO 1 1 1
22 99530–10114 PINO GUIA 2 2
23 99530–10114 PINO GUIA 2 2
24 90110–06378 PARAFUSO HEXAGONAL INTERNO 2 2
25 B6H–E1311–00 CILINDRO 1 1 1
26 B6H–E1351–00 GAXETA DO CILINDRO 1 1
1
FIG. 1 CILINDRO
REF.
BNN1
BNN2
NO.
28 90430–06803 GAXETA 1 1
2
FIG. 2 VIRABREQUIM E PISTAO
REF.
BNN1
BNN2
NO.
1 B6H–E1400–40 VIRABREQUIM CONJ. 1 1
2 B63–E1681–00 .PINO DO VIRABREQUIM 1 1 1
3 93310–528YK .ROLAMENTO 1 1
4 2DP–E1651–00 .BIELA 1 1
5 90280–03017 CHAVETA MEIA LUA 1 1
6 BK6–E1631–00 PISTAO (STD) 1 1
7 2DP–E1633–00 PINO DO PISTAO 1 1
8 93450–16115 ANEL TRAVA 2 2
9 B63–E1603–00 JOGO DE ANEIS (STD) 1 1
3
FIG. 3 VALVULA
REF.
BNN1
BNN2
NO.
1 BK6–E2111–00 VALVULA DE ADMISSAO 2 2
2 B3F–E2121–00 VALVULA DE ESCAPE 2 2
3 54P–E2119–00 RETENTOR DA HASTE DA VALVULA 4 4
4 BB8–E2113–01 MOLA INTERNA DA VALVULA 4 4
5 5TL–E2118–00 TRAVA DA VALVULA 8 8
6 2DP–E2117–00 ASSENTO SUPERIOR DA MOLA 4 4
7 50C–E2126–00 ASSENTO DA MOLA DA VALVULA 2 4 4
8 B55–E2150–01 BRACO DO BALANCIM DA VALVULA 1 1
9 33S–E2159–01 .PARAFUSO DE AJUSTE DA VALVULA 2 2
10 90170–05803 .PORCA 2 2
11 BB8–E2226–00 MOLA DO BRACO 1 1
12 2DP–E2279–00 PLACA DE FIXACAO 1 1
13 B6H–E2160–00 BRACO DO BALANCIM DA VALVULA 2 1 1
14 33S–E2159–01 .PARAFUSO DE AJUSTE DA VALVULA 2 2
15 90170–05803 .PORCA 2 2
16 45P–E2156–00 EIXO DO BALANCIM 2 2 2
17 91312–05016 PARAFUSO HEXAGONAL 2 2
18 2DP–E111F–00 PLACA DE FIXACAO 1 1
4
FIG. 4 CORRENTE DO EIXO DE COMANDO
REF.
BNN1
BNN2
NO.
1 BBR–E2170–00 EIXO DE COMANDO COMPLETO 1 1 1
2 93210–09805 .ANEL DE BORRACHA 1 1
3 93306–001X9 ROLAMENTO 1 1
4 B6H–E2280–10 DESCOMPRESSOR COMPLETO 1 1
5 2DP–E2288–00 CAME DE DESCOMPRESSAO 1 1
6 5YP–E2157–01 PARAFUSO 1 1
7 94568–F9096 CORRENTE (DID SCR-0404 SV) 1 1
8 B65–E2231–00 GUIA LIMITADORA 1 1 1
9 B6H–E2241–00 GUIA LIMITADORA 2 1 1
10 1DB–E2228–00 PARAFUSO 1 1
11 2PV–E2210–01 TENSIONADOR DA CORRENTE CONJ. 1 1
12 B6H–E2213–00 GAXETA DA CAIXA DO TENSIONADOR 1 1
5
FIG. 5 BOMBA DE AGUA
REF.
BNN1
BNN2
NO.
1 B6H–E2422–00 TAMPA DA CAIXA 1 1
2 B6H–E2223–00 VEDACAO 1 1
3 B6H–E2439–00 ANEL DE BORRACHA 1 1
4 B6H–E1185–00 TAMPA LATERAL DO CABECOTE 3 1 1
5 B6H–E2450–00 EIXO IMPULSOR COMPLETO 1 1
6 99009–08400 ANEL TRAVA 1 1
7 93300–608X0 ROLAMENTO 2 2
8 95027–06020 PARAFUSO FLANGE 3 3
9 90430–06803 GAXETA 1 1
10 99530–08012 PINO GUIA 2 2
11 93210–39803 ANEL DE BORRACHA 1 1
6
FIG. 6 RADIADOR E MANGUEIRAS
REF.
BNN1
BNN2
NO.
1 2DP–E2410–00 TERMOSTATO CONJUNTO 1 1
2 52S–12439–00 .ANEL DE BORRACHA 1 1
4 B6H–E240A–01 RADIADOR CONJUNTO 1 1
5 B65–E2462–02 .TAMPA DO RADIADOR 1 1
6 B63–E22A2–00 .ANEL DE BORRACHA 1 1
7 B63–E2439–00 .ANEL DE BORRACHA 1 1
8 B63–E2843–00 .ANEL DE BORRACHA 1 1
9 5ST–E2615–00 .DRENO 1 1
10 5ST–E2843–00 .ANEL DE BORRACHA 1 1
11 90387–08823 ESPACADOR 4 4
12 90480–14833 ILHO DE BORRACHA 4 4
13 95D32–06030 PARAFUSO FLANGE 4 4
14 90467–20806 PRESILHA 1 1
15 90467–19803 PRESILHA 3 3
16 90467–19803 PRESILHA 2 2
17 B6H–E2481–10 TUBO 1 1 1
18 B6H–E2482–00 TUBO 2 1 1
19 B6H–E2483–00 TUBO 3 1 1
20 B6H–E2491–00 BRACADEIRA 1 1 1
21 B6H–E2621–01 CAIXA DO VENTILADOR 1 1
22 90520–10853 PLACA AMORTIZADORA 2 2
25 BBB–E2467–00 TAMPA DO RADIADOR 1 1
27 B65–E2611–00 VENTOINHA 1 1
7
FIG. 6 RADIADOR E MANGUEIRAS
REF.
BNN1
BNN2
NO.
29 BAL–E8179–00 GUIA 1 1
8
FIG. 7 BOMBA DE OLEO
REF.
BNN1
BNN2
NO.
1 B6H–E3300–01 BOMBA DE OLEO COMPLETA 1 1
2 98502–05020 PARAFUSO CABECA DE PANELA 2 2
3 54P–E5351–01 TAMPAO DO DRENO 1 1
4 54P–E3411–00 FILTRADOR DE OLEO 1 1
5 90501–16004 MOLA DE COMPRESSAO 1 1
9
FIG. 8 ADMISSAO
REF.
BNN1
BNN2
NO.
1 B6H–E3585–00 TUBO MULTIPLO 1 1
2 B6H–E4199–00 GAXETA 1 1
3 91332–06025 PARAFUSO 2 2
4 B6H–E4146–00 PLACA 1 1
5 BB8–E3770–10 INJETOR CONJUNTO 1 1
6 BB8–E3761–10 .INJETOR CONJUNTO 1 1
7 54P–E4147–00 ..ANEL DE BORRACHA 1 1
8 5CA–E4147–00 ..ANEL DE BORRACHA 1 1
9 54P–E3938–00 .TUBO 1 1
10 54P–E4137–00 .PRESILHA 1 1
12 2DP–E3556–00 GAXETA DO TUBO MULTIPLO 1 1
13 B3V–E3750–01 CORPO DE ACELERACAO CONJ. 1 1
14 98502–06012 .PARAFUSO 2 2
15 54P–E4243–00 .PLACA DE FIXACAO 1 1
16 54P–E4335–00 .MOLA 1 1
17 54P–E416A–00 .ANEL DE BORRACHA 1 1
18 B63–H5801–01 .SENSOR DO PASSO DO MOTOR 1 1
20 B6H–E4411–10 CAIXA DO FILTRO DE AR 1 1 1
21 B6H–E4412–10 TAMPA DA CAIXA DO FILTRO 1 1 1
22 B6H–E4437–00 DUTO 1 1
23 B6H–E4453–00 JUNCAO DA CAIXA DO FILTRO 1 1 1
24 B6H–E4451–00 ELEMENTO DO FILTRO DE AR 1 1
25 B6H–E4452–10 VEDACAO 2 2
26 97707–50025 PARAFUSO 9 9
27 5TL–E443E–00 TUBO DE DRENO 1 1
10
FIG. 8 ADMISSAO
REF.
BNN1
BNN2
NO.
28 B5D–E443G–00 TUBO DE DRENO 2 1 1
29 90467–12809 PRESILHA 1 1
30 B74–E4449–00 ESPACADOR 2 2
31 B6H–E4435–00 ILHO 2 2
34 90450–43805 BRACADEIRA DO TUBO 1 1
35 B6H–E1166–00 TUBO DE RESPIRO 1 1 1
36 90467–11825 PRESILHA 1 1
37 90467–12052 PRESILHA 1 1
11
FIG. 9 ESCAPAMENTO
REF.
BNN1
BNN2
NO.
1 BNN–E4711–10 SILENCIADOR 1 1 1
2 B3V–E4718–00 PROTETOR DO SILENCIADOR 1 1 1
3 90111–06860 PARAFUSO 2 2
4 2DP–E4613–00 GAXETA DO TUBO DE ESCAPE 1 1
5 95702–08500 PORCA FLANGE 2 2
12
FIG. 10 CARCACA DO MOTOR
REF.
BNN1
BNN2
NO.
1 B6H–E5150–00 CARCACA DO MOTOR COMPLETA 1 1
2 99480–03012 PINO 1 1
3 54P–F7121–00 BUCHA 2 2
4 90388–10808 BUCHA AMORTIZADORA 2 2
6 99530–10114 PINO GUIA 2 2
10 90340–12816 TAMPAO DO DRENO 1 1
11 90430–12803 GAXETA 1 1
13 90430–08804 GAXETA 1 1
14 B55–E5362–00 TAMPAO DO NIVEL DE OLEO 1 1
15 5LW–E3769–00 ANEL DE BORRACHA 1 1
16 5LW–E5363–00 TAMPAO DO NIVEL DE OLEO 1 1
18 B65–E5423–01 TAMPA 2 1 1
21 99530–10114 PINO GUIA 2 2
24 B6H–E5421–00 TAMPA DA CARCACA 2 1 1
25 B6H–E5461–10 GAXETA DA TAMPA DA CARCACA 2 1 1
26 99530–10114 PINO GUIA 2 2
13
FIG. 10 CARCACA DO MOTOR
REF.
BNN1
BNN2
NO.
29 B6H–E5371–00 RESPIRO 1 1
30 B6H–E5373–00 TUBO DO RESPIRO 1 1
31 90467–10008 PRESILHA 1 1
32 90467–11825 PRESILHA 1 1
14
FIG. 11 TAMPA DA CARCACA 1
REF.
BNN1
BNN2
NO.
2 B6H–E5451–00 GAXETA DA TAMPA DA CARCACA 1 1 1
3 99530–10114 PINO GUIA 1 1
5 5LW–E5371–01 RESPIRO 1 1
6 4ST–E443E–00 TUBO DE DRENO 1 1
7 90467–11106 PRESILHA 1 1
9 B3V–E5495–00 VEDACAO DO PROTETOR 1 1 1
10 B65–E5472–00 VEDACAO DO DUTO DE AR 1 1
11 B6H–E5407–00 ELEMENTO 1 1 1
12 B63–E5481–00 PARAFUSO 1 6 6
13 2DP–E5474–00 VEDACAO DO DUTO DE AR 1 1
14 B6H–E5316–00 AMORTIZADOR 1 1 1
15 B6H–E5326–00 AMORTIZADOR 2 1 1
20 B6H–E533C–00 AMORTIZADOR 7 1 1
22 B6H–E533E–00 AMORTIZADOR 9 1 1
15
FIG. 12 EMBREAGEM
REF.
BNN1
BNN2
NO.
1 B3V–E7620–10 ROLDANA PRIMARIA COMPLETA 1 1
2 BBP–E7632–00 CONTRAPESO 6 6
3 2DP–E7623–00 CAMES 1 1
4 44D–E7653–00 CORREDICA 3 3
5 B6H–E7674–00 ESPACADOR GUIA 1 1
6 B55–E7611–00 ROLDANA PRIMARIA DA PARTIDA 1 1
7 BBP–E6620–00 EMBREAGEM CENTRIFUGA CONJUNTO 1 1
8 B65–WE662–00 .KIT PESO DA EMBREAGEM 3 3
9 B65–E6626–00 .MOLA DO PESO DA EMBREAGEM 1 3 3
10 B6H–E7660–00 ROLDANA SECUNDARIA FIXA COMP. 1 1
11 BBP–E7670–00 ROLDANA SECUNDARIA MOVEL 1 1
12 2DP–E7465–00 VEDACAO 2 2
13 2DP–E7465–10 VEDACAO 2 2
14 B74–E7664–00 PINO GUIA 3 3
15 B63–E7674–10 ESPACADOR GUIA 3 3
16 BBP–E7683–00 MOLA SECUNDARIA 1 1
17 2DP–E7684–00 ASSENTO DA MOLA SECUNDARIA 1 1
18 2DP–E7668–00 PORCA 1 1
19 B6H–E7678–00 ROLAMENTO 1 1
20 2DP–E5744–00 ANEL TRAVA 1 1
21 2DP–E7678–10 ROLAMENTO 1 1
22 BBP–E6611–00 CAIXA DA EMBREAGEM COMP. 1 1
23 B8R–E7641–00 CORREIA 1 1
24 90201–16819 ARRUELA PLANA 1 1
25 90201–15849 ARRUELA PLANA 1 1
26 90179–12004 PORCA 1 1
27 90170–12802 PORCA 1 1
16
FIG. 12 EMBREAGEM
REF.
BNN1
BNN2
NO.
28 933A6–202Y0 ROLAMENTO 1 1
29 90380–10800 BUCHA SOLIDA 1 1
30 99009–35700 ANEL TRAVA 1 1
31 90201–15847 ARRUELA PLANA 1 1
17
FIG. 13 TRANSMISSAO
REF.
BNN1
BNN2
NO.
1 2DP–E7410–02 EIXO PRINCIPAL COMP. (12D/56D) 1 1
2 93306–302YU ROLAMENTO 2 2
3 B6H–E7421–00 EIXO SECUNDARIO 1 1
4 2DP–E7211–01 ENGRENAGEM MOVIDA DA 1A (35D) 1 1
5 99009–25400 ANEL TRAVA 1 1
6 93306–303YW ROLAMENTO 1 1
7 93306–255X2 ROLAMENTO 1 1
9 B65–E6111–01 ENGRENAGEM MOTORA PRIMARIA 16D 1 1
10 93306–254Y2 ROLAMENTO 1 1
12 93306–301XT ROLAMENTO 1 1
18
FIG. 14 CHASSI
REF.
BNN1
BNN2
NO.
1 BNN–F1110–01 CHASSI COMPLETO 1 1
2 B3V–H251P–00 SUPORTE DO INTERRUPTOR PRINC. 1 1
3 90109–068D5 PARAFUSO 2 2
4 5D9–F414G–00 VEDACAO 3 3
5 B6H–F1410–00 SUPORTE DO MOTOR COMPLETO 1 1
6 B3V–F117G–00 PROTETOR 1 1
8 90387–10857 ESPACADOR 1 1
9 B65–F113B–00 AMORTIZADOR 1 1
10 B3V–F2141–00 EIXO DO PIVO 1 1
11 95602–10200 PORCA AUTOTRAVANTE 1 1
14 44D–F7114–00 LIMITADOR 2 2
15 90387–08821 ESPACADOR 2 2
16 90105–088E3 PARAFUSO FLANGE 2 2
17 95602–08200 PORCA AUTO-TRAVANTE 2 2
18 B6H–F8356–00 FIXADOR 1 1 1
20 90179–05003 PORCA 4 4
22 90387–068N8 ESPACADOR 3 3
24 90105–068C5 PARAFUSO FLANGE 1 1
26 B3V–F588F–00 SUPORTE MANGUEIRA DE FREIO 5 1 1
19
FIG. 14 CHASSI
REF.
BNN1
BNN2
NO.
28 B55–F111M–00 ETIQUETA DE FABRICACAO LOCAL 1 1
20
FIG. 15 PARA-LAMA
REF.
BNN1
BNN2
NO.
1 B55–F1511–00–P3 PARA-LAMA DIANTEIRO 1 DPBMU
B55–F1511–00–P7 PARA-LAMA DIANTEIRO 1 RSH
B55–F1511–00–P8 PARA-LAMA DIANTEIRO 1 MDBNM4
B55–F1511–00–P2 PARA-LAMA DIANTEIRO 1 MBL2 PARA MNM3
2 5D9–F414G–00 VEDACAO 1 1
3 90109–068A4 PARAFUSO 4 4
4 B6H–F1552–01 PARA-LAMA INTERNO 1 1
5 90269–06816 REBITE 8 8
6 B6H–F1611–20 PARA-LAMA TRASEIRO 1 1
7 90109–068B2 PARAFUSO 2 2
8 90109–068C7 PARAFUSO 2
90109–068C6 PARAFUSO 2
9 B6H–F162R–01 PARA-LAMA 2 1 1
10 97702–50016 PARAFUSO 3 3
11 B5D–F465B–00 TAMPA DO ROTOR 1 1
12 B65–F465E–00 ROTOR COMPLETO 1 1
13 B3V–F117K–00 SUPORTE DA TRAVA 1 1
15 90183–06818 PORCA MOLA 1 1
16 BC5–F1578–01 EMBLEMA ABS 2 2
21
FIG. 16 TAMPA LATERAL
REF.
BNN1
BNN2
NO.
1 B3V–F1711–00–P2 TAMPA LATERAL 1 1 DPBMU
B3V–F1711–00–P5 TAMPA LATERAL 1 1 RSH
B3V–F1711–00–P6 TAMPA LATERAL 1 1 MDBNM4
B3V–F1711–00–P7 TAMPA LATERAL 1 1 MNM3
2 90183–05807 PORCA MOLA 1 1
3 90269–06816 REBITE 2 2
5 B3V–F1721–00–P2 TAMPA LATERAL 2 1 DPBMU
B3V–F1721–00–P5 TAMPA LATERAL 2 1 RSH
B3V–F1721–00–P6 TAMPA LATERAL 2 1 MDBNM4
6 90183–05807 PORCA MOLA 1 1
7 90269–06816 REBITE 2 2
9 B3V–F171E–00 TAMPA LATERAL 5 1 1
10 90183–06815 PORCA MOLA 1 1
11 B3V–F171X–00 TAMPA LATERAL 6 1 1
12 90183–06815 PORCA MOLA 1 1
13 B3V–H4716–00 TAMPA LANTERNA TRASEIRA 1 1
14 97707–50016 PARAFUSO 2 2
15 B3V–F1651–00–P2 TAMPA DO PARA-LAMA TRASEIRO 1 DPBMU
B3V–F1651–00–P5 TAMPA DO PARA-LAMA TRASEIRO 1 RSH
B3V–F1651–00–P6 TAMPA DO PARA-LAMA TRASEIRO 1 MDBNM4
B3V–F1651–00–P7 TAMPA DO PARA-LAMA TRASEIRO 1 MNM3
16 90464–07018 BRACADEIRA 1 1
17 97702–50016 PARAFUSO 2 2
18 B3V–F1731–00–P0 TAMPA LATERAL 3 1 SMX
22
FIG. 16 TAMPA LATERAL
REF.
BNN1
BNN2
NO.
18 B3V–F1731–00–P2 TAMPA LATERAL 3 1 MNM3
19 90160–05810 PARAFUSO 3 3
21 B3V–F1741–00–P0 TAMPA LATERAL 4 1 SMX
22 90160–05810 PARAFUSO 3 3
24 B65–F1871–00 TANQUE DE RECUPERACAO 1 1
25 B6H–F1746–00 AMORTIZADOR 1 1
26 90109–068B2 PARAFUSO 1 1
28 1S7–F1875–01 TAMPA 1 1
29 B6H–F1816–10 TUBO 1 1 1
30 90464–30001 BRACADEIRA 1 1
31 B6H–F1817–10 TUBO 2 1 1
32 90467–08003 PRESILHA 2 2
33 90464–07805 BRACADEIRA 2 2
34 B6H–F173B–00 EMBLEMA 3D 2 UR PARA DPBMU
B6H–F173B–50 EMBLEMA 3D 2 UR P/ RSH,MDBNM4
35 BNN–F173L–00 JOGO GRAFICO 1 1 UR PARA MNM3
36 BNN–F174L–00 JOGO GRAFICO 2 1 UR PARA MNM3
37 BNN–F174G–00 GRAFICO 3 1 UR PARA MNM3
38 BNN–F174H–00 GRAFICO 4 1 UR PARA MNM3
23
FIG. 17 GARFO TRASEIRO. SUSPENSAO 1
REF.
BNN1
BNN2
NO.
1 B6H–F2171–10 GARFO TRASEIRO 1 1 1
4 93306–303YX ROLAMENTO 1 1
5 90387–17807 ESPACADOR 1 1
6 B55–F2117–00 TAMPA 1 1
8 B6H–F588G–10 SUPORTE MANGUEIRA DE FREIO 6 1 1
9 90387–17808 ESPACADOR 1 1
11 B6H–F5886–00 SUPORTE DA MANGUEIRA DE FREIO 1 1
13 90464–16006 BRACADEIRA 1 1
14 BBB–F2210–00 AMORTECEDOR TRASEIRO CONJ. 2 2
15 90105–088E8 PARAFUSO FLANGE 2 2
16 90105–108C1 PARAFUSO FLANGE 2 2
17 90201–10853 ARRUELA PLANA 4 4
18 95302–10600 PORCA 2 2
24
FIG. 18 GARFO DIANTEIRO
REF.
BNN1
BNN2
NO.
1 B6H–F3102–00 GARFO DIANTEIRO CONJ. (ESQ.) 1 1
2 2DP–F3126–00 .TUBO EXTERNO 1 1 1
3 3HB–F3145–00 ..RETENTOR DE OLEO DO GARFO 1 1
4 3V3–F3156–00 ..CLIPE DO RETENTOR DE OLEO 1 1
5 3HB–F3144–00 ..PROTETOR DE POEIRA 1 1
6 2DP–F3110–00 .TUBO INTERNO COMPLETO 1 1 1
7 2DP–F3170–00 .CILINDRO COMPLETO DO GARFO 1 1
8 2K5–23152–00 ..MOLA 1 1
9 2DP–F3157–00 ..ANEL TRAVA DO PISTAO 1 1
10 2DP–F3173–00 .VALVULA DE PRESSAO DO OLEO 1 1
11 2BU–F3158–00 .GAXETA 1 1
12 278–F3181–50 .PARAFUSO DO GARFO DIANTEIRO 1 1
13 B6H–F3141–00 .MOLA DO GARFO DIANTEIRO 1 1
14 3Y6–23114–00 .GAXETA DE VEDACAO 1 1
15 2DP–F3111–00 .CAPA DO PARAFUSO 1 1
16 2DP–F3153–00 .ANEL TRAVA 1 1
17 B6H–F3103–00 GARFO DIANTEIRO CONJ. (DIR.) 1 1
18 2DP–F3136–00 .TUBO EXTERNO 2 1 1
19 3HB–F3145–00 ..RETENTOR DE OLEO DO GARFO 1 1
20 3V3–F3156–00 ..CLIPE DO RETENTOR DE OLEO 1 1
21 3HB–F3144–00 ..PROTETOR DE POEIRA 1 1
22 2DP–F3110–00 .TUBO INTERNO COMPLETO 1 1 1
23 2DP–F3170–00 .CILINDRO COMPLETO DO GARFO 1 1
24 2K5–23152–00 ..MOLA 1 1
25 2DP–F3157–00 ..ANEL TRAVA DO PISTAO 1 1
26 2DP–F3173–00 .VALVULA DE PRESSAO DO OLEO 1 1
27 2BU–F3158–00 .GAXETA 1 1
25
FIG. 18 GARFO DIANTEIRO
REF.
BNN1
BNN2
NO.
28 278–F3181–50 .PARAFUSO DO GARFO DIANTEIRO 1 1
29 B6H–F3141–00 .MOLA DO GARFO DIANTEIRO 1 1
30 3Y6–23114–00 .GAXETA DE VEDACAO 1 1
31 2DP–F3111–00 .CAPA DO PARAFUSO 1 1
32 2DP–F3153–00 .ANEL TRAVA 1 1
33 B6H–F3340–00 SUPORTE INFERIOR COMPLETO 1 1
34 B63–F3462–00 VEDACAO DA DIRECAO 1 1
35 5YW–F3346–10 PARAFUSO 1 4 4
36 1KL–F3412–10 PISTA DE ESFERAS 2 1 1
37 5VL–F341E–10 JOGO DE ESFERAS 1 1
38 4FP–F3411–10 PISTA DE ESFERAS 1 1 1
39 4RT–F3412–10 PISTA DE ESFERAS 2 1 1
40 4RT–F3411–10 PISTA DE ESFERAS 1 1 1
41 1P6–F341E–10 JOGO DE ESFERAS 1 1
42 B3V–F3416–00 CAPA DA PISTA DE ESFERA 2 1 1
43 B3V–F3415–00 CAPA DA PISTA DE ESFERA 1 1 1
44 90179–25810 PORCA 3 3
45 90202–26142 ARRUELA PLANA 1 1
46 1SK–F3418–00 ARRUELA ESPECIAL 1 1
47 B6H–F312G–00 TAMPAO 1 1
48 B65–F3123–00 CAPA INFERIOR 1 1 1
49 B6H–F5875–00 SUPORTE MANGUEIRA DE FREIO 1 1 1
51 B6H–F5876–00 SUPORTE MANGUEIRA DE FREIO 2 1 1
26
FIG. 19 TANQUE DE COMBUSTIVEL
REF.
BNN1
BNN2
NO.
1 B6H–F4110–01 TANQUE DE COMBUSTIVEL COMP. 1 1
2 90119–068B7 PARAFUSO COM ARRUELA 4 4
4 B6H–E3971–00 TUBO DE COMBUSTIVEL 1 1 1
5 B6H–E3907–01 BOMBA DE COMBUSTIVEL COMPLETA 1 1
6 54P–E3915–00 .FILTRO 1 1
7 BK6–H5752–00 .UNIDADE SENSOR DE COMB. CONJ. 1 1
8 54P–F414G–10 VEDACAO 1 1
9 B6H–F4491–00 SUPORTE BOMBA DE COMBUSTIVEL 1 1
11 B6H–F4610–01 TAMPA DO TANQUE CJ. 1 1
12 B3V–F414A–01 TAMPA DE ENCHIMENTO 1 1
13 B3V–F4217–00 .CAPA 1 1
14 B6H–F4318–01 .TUBO DE TRANSBORDO 1 1
15 90464–30001 BRACADEIRA 1 1
16 B6H–F419A–10 FIXADOR 1 1
18 90464–14002 BRACADEIRA 2 2
19 5D9–F414G–00 VEDACAO 1 1
20 5TP–F139X–00 AMORTIZADOR 1 1
27
FIG. 20 ASSENTO
REF.
BNN1
BNN2
NO.
1 B6H–F4730–01 SELIM DUPLO COMPLETO 1 1
2 B6H–F470F–01 .CAPA DO SELIM 1 1
3 5BP–F4741–00 .AMORTIZADOR 2 2
4 3C1–F4741–00 .AMORTIZADOR 1 1
5 B6H–F475M–00 .VEDACAO 1 1
6 95702–06500 PORCA FLANGE 3 3
7 B6Y–F473R–00 CAIXA DO ASSENTO 1 1 1
9 90109–068B2 PARAFUSO 4 4
10 90183–05807 PORCA MOLA 4 4
11 4US–F6199–00 TAMPAO CEGO 1 1
12 B6H–F4769–00 DOBRADICA DO SELIM 1 1
13 90468–08086 PRESILHA 1 1
14 B6H–F4811–00 GANCHO 1 1
15 90506–23815 MOLA DE TENSAO 2 2
16 BDC–F4727–00 PINO DE FIXACAO DO SELIM 1 1
17 90468–18121 PRESILHA 1 1
18 B6H–F472A–00 SUPORTE 1 1
19 B6H–F247C–00 MANGUEIRA 3 2 2
20 90119–06212 PARAFUSO COM ARRUELA 2 2
21 B6H–F478E–10 CABO DA TRAVA DO SELIM 1 1
22 B65–F4780–00 TRAVA DO SELIM CONJ. 1 1
24 1S7–F4768–00 LIMITADOR 1 1
25 B6H–F472T–01 TAMPA DA TRAVA DO SELIM 1 1
26 90269–06816 REBITE 2 2
27 B6H–F4773–10 APOIO PASSAGEIRO 1 1
28
FIG. 20 ASSENTO
REF.
BNN1
BNN2
NO.
29 90201–08884 ARRUELA PLANA 4 4
30 90387–08847 ESPACADOR 2 2
31 90387–10867 ESPACADOR 2 2
33 B6H–H2129–11 TAMPA DA BATERIA 1 1
34 97707–50012 PARAFUSO 2 2
35 B3V–F1621–00 ABA 1 1
36 90269–06812 REBITE 3 3
37 B6H–F842N–00 TAMPA 2 1 1
38 90111–05816 PARAFUSO 1 1
39 B6H–F479D–00 CABO DA TRAVA DO SELIM 2 1 1
40 2DP–F814F–00 CHAVE DE VELA 1 1
41 3AY–F8152–00 CHAVE DE FENDA / PHILIPS 1 1
42 BNN–F8199–W0 MANUAL DO PROPRIETARIO 1 1
43 B55–F1668–01 ETIQUETA DE PRESSAO DO PNEU 1 1
44 B55–F111F–00 ETIQUETA DE EMISSAO 1 1
45 5HH–F178A–00 ETIQUETA YAMALUBE 1 1
46 B1S–F118K–00 ETIQUETA DE ATENCAO 1 1
29
FIG. 21 RODA DIANTEIRA 1
REF.
BNN1
BNN2
NO.
1 B6H–F5168–00–P3 ARO DA RODA DIANTEIRA 1 MNYM3 P/ MDBNM4
B6H–F5168–00–33 ARO DA RODA DIANTEIRA 1 1 YB PARA OUTRAS
2 90387–10839 ESPACADOR 1 1
4 93306–300YN ROLAMENTO 2 2
5 2DP–F517G–00 ROTOR DO SENSOR 1 1
6 90149–05030 PARAFUSO 3 3
7 94111–13805 PNEU (110/70-13M/C TL 48P) 1 1 PIRELLI
8 93900–00824 VALVULA ARO DA RODA 1 1
9 90387–10277 ESPACADOR 2 2
10 B55–F5181–00 EIXO DA RODA 1 1
12 90201–10831 ARRUELA PLANA 1 1
30
FIG. 22 PINCA DE FREIO DIANTEIRA
REF.
BNN1
BNN2
NO.
1 2DP–F582U–00 DISCO DE FREIO (DIR.) 1 1
2 90109–08232 PARAFUSO 3 3
3 B6H–F580U–00 PINCA DO FREIO CONJ. (DIR.) 1 1
4 2BM–F5802–00 .JOGO DE PISTOES DA PINCA 1 1
5 5YP–F5803–50 ..JOGO DE RETENTORES DA PINCA 1 1
6 2BM–F5917–00 .PROTETOR DA PINCA 1 1
7 5YP–F5937–00 .CAPA DA PINCA DE FREIO 1 1
8 4C9–W0048–00 .KIT DO PARAFUSO SANGRADOR 1 1
9 2DP–F5805–00 .KIT DE PASTILHAS DE FREIO 1 1
10 5YP–F5925–01 .PRESILHA 2 2
11 2BM–F5919–00 .SUPORTE DA PASTILHA DE FREIO 1 1
12 5YP–F5924–00 .PINO DA PASTILHA DE FREIO 1 1
13 2DP–F5920–00 .SUPORTE DE APOIO CONJ. 1 1
14 2R6–F5916–00 .PLUGUE 1 1
15 B8A–F5827–00 .CALCO DA PINCA 1 1
16 90149–10805 PARAFUSO 2 2
31
FIG. 23 RODA TRASEIRA 1
REF.
BNN1
BNN2
NO.
1 B6H–F5338–00–P3 ARO DA RODA TRASEIRA 1 MNYM3 P/ MDBNM4
B6H–F5338–00–33 ARO DA RODA TRASEIRA 1 1 YB PARA OUTRAS
2 2DP–F517G–00 ROTOR DO SENSOR 1 1
3 90149–05030 PARAFUSO 3 3
4 94113–13811 PNEU (130/70-13M/C TL 63P) 1 1 PIRELLI
5 93900–00824 VALVULA ARO DA RODA 1 1
32
FIG. 24 PINCA DE FREIO TRASEIRA
REF.
BNN1
BNN2
NO.
1 2DP–F582W–00 DISCO DE FREIO TRAS. 2 1 1
2 90109–08232 PARAFUSO 3 3
3 B6H–F580W–00 PINCA FREIO CONJ. TRASEIRO 2 1 1
4 5P0–F5802–00 .JOGO DE PISTOES DA PINCA 1 1
5 5YP–F5803–50 ..JOGO DE RETENTORES DA PINCA 1 1
6 5YP–F5917–00 .PROTETOR DA PINCA 1 1
7 5YP–F5937–00 .CAPA DA PINCA DE FREIO 1 1
8 4C9–W0048–00 .KIT DO PARAFUSO SANGRADOR 1 1
9 B6H–F5805–00 .KIT DE PASTILHAS DE FREIO 1 1
10 5YP–F5925–01 .PRESILHA 2 2
11 5P0–F5919–01 .SUPORTE DA PASTILHA DE FREIO 1 1
12 5YP–F5924–00 .PINO DA PASTILHA DE FREIO 1 1
13 2DP–F5920–50 .SUPORTE DE APOIO CONJ. 1 1
14 2R6–F5916–00 .PLUGUE 1 1
15 5P0–F5827–00 .CALCO DA PINCA 2 2
33
FIG. 25 GUIDAO E CABOS
REF.
BNN1
BNN2
NO.
1 B6H–F6110–01 GUIDAO COMPLETO 1 1
2 90105–108B0 PARAFUSO FLANGE 1 1
4 B3V–F6240–00 MANOPLA DIREITA CONJ. 1 1
5 B01–F6241–00 MANOPLA ESQUERDA 1 1
6 2PH–F6246–00 TERMINACAO DA MANOPLA 2 2
7 2DP–F6280–10 ESPELHO RETROVISOR CONJ. (ESQ) 1 1
8 2DP–F6290–10 ESPELHO RETROVISOR CONJ. (DIR) 1 1
9 B6H–F6301–10 CABO ACELERADOR CONJ. 1 1
10 90464–08009 BRACADEIRA 2 2
11 92017–05016 PARAFUSO 1 1
13 90464–16808 BRACADEIRA 1 1
14 90464–24230 BRACADEIRA 2 2
15 90464–07807 BRACADEIRA 1 1
16 B6H–F6143–00 TAMPA SUPERIOR DO GUIDAO 1 1 1
17 90183–06818 PORCA MOLA 1 1
19 B3V–F6219–00–P0 CAPA DA TAMPA DO GUIDAO 1 1 MNM3
21 90149–06104 PARAFUSO 1 1
22 B3V–F6144–00 TAMPA INFERIOR DO GUIDAO 1 1 1
23 90269–06816 REBITE 2 2
25 90160–05014 PARAFUSO 2 2
26 40D–F1737–00 EMBLEMA 1 1
27 B55–F1737–00 EMBLEMA 1 1
34
FIG. 25 GUIDAO E CABOS
REF.
BNN1
BNN2
NO.
28 B6H–F8368–00 EMBLEMA 1 1
35
FIG. 26 CILINDRO MESTRE DIANTEIRO
REF.
BNN1
BNN2
NO.
1 B6H–F583T–00 CILINDRO MESTRE DIANTEIRO CJ. 1 1
2 2DP–F5807–00 .KIT DE REPARO DO CILINDRO 1 1
3 2DP–F5852–00 .TAMPA DO RESERVATORIO 1 1
4 5HV–F585B–10 .PLACA DO DIAFRAGMA 1 1
5 5HV–F5854–10 .DIAFRAGMA DO RESERVATORIO 1 1
6 98707–04012 .PARAFUSO CABECA PLANA 2 2
7 2DP–H3922–00 .ALAVANCA DIREITA 1 1
8 2DP–F589F–00 .PARAFUSO DA ALAVANCA 1 1
9 95602–06100 .PORCA AUTOTRAVANTE 1 1
10 2DP–F5867–10 .SUPORTE DO CILINDRO MESTRE 1 1
11 1S9–F6332–00 .PARAFUSO 2 2
12 B6H–H3980–00 .INTERRUPTOR DE FREIO DIANT. 1 1
13 97602–04312 .PARAFUSO CABECA DE PANELA 1 1
14 B6H–F6257–10 LIMITADOR 1 1
15 B6H–F5872–00 MANGUEIRA DE FREIO 1 1 1
16 90401–10812 PARAFUSO DE UNIAO 2 2
17 90201–10118 ARRUELA PLANA 4 4
20 90201–10118 ARRUELA PLANA 4 4
21 B6H–F583V–00 CILINDRO MESTRE TRASEIRO CONJ. 1 1
22 2DP–F5807–10 .KIT DE REPARO DO CILINDRO 1 1
23 2DP–F5852–00 .TAMPA DO RESERVATORIO 1 1
24 5HV–F585B–10 .PLACA DO DIAFRAGMA 1 1
25 5HV–F5854–10 .DIAFRAGMA DO RESERVATORIO 1 1
26 98707–04012 .PARAFUSO CABECA PLANA 2 2
27 2DP–H3912–00 .ALAVANCA ESQUERDA 1 1 1
36
FIG. 26 CILINDRO MESTRE DIANTEIRO
REF.
BNN1
BNN2
NO.
28 2DP–F589F–00 .PARAFUSO DA ALAVANCA 1 1
29 95602–06100 .PORCA AUTOTRAVANTE 1 1
30 2DP–F5867–00 .SUPORTE DO CILINDRO MESTRE 1 1
31 1S9–F6332–00 .PARAFUSO 2 2
32 B6H–H2530–00 .INTERRUPTOR DE PARADA CONJ. 1 1
33 97602–04312 .PARAFUSO CABECA DE PANELA 1 1
36 90201–10118 ARRUELA PLANA 4 4
37 90464–07014 BRACADEIRA 1 1
38 B6H–F581J–10 MANGUEIRA DE FREIO 4 1 1
40 90201–10118 ARRUELA PLANA 4 4
41 90464–16808 BRACADEIRA 1 1
42 BNN–F5887–00 SUPORTE DA MANGUEIRA DE FREIO 1 1
44 BAL–F5522–00 SUPORTE 1 1
45 90464–07805 BRACADEIRA 1 1
46 B6H–F194U–00 SUPORTE DA BOBINA DE IGNICAO 1 1
48 B6H–F587A–00 SUPORTE DA MANGUEIRA DE FREIO 1 1
37
FIG. 27 CAVALETE. ESTRIBOS. PEDAL
REF.
BNN1
BNN2
NO.
1 B6H–F7111–00 CAVALETE CENTRAL 1 1
2 B6H–F7112–00 EIXO DO CAVALETE CENTRAL 1 1
3 99002–09600 ANEL TRAVA 1 1
4 54P–F7114–00 LIMITADOR 1 1
5 90506–40806 MOLA DE TENSAO 1 1
6 B6H–F247A–00 MANGUEIRA 1 1 1
7 1LB–F7254–00 GANCHO 1 1
8 B3V–F7311–01 CAVALETE LATERAL 1 1
9 B65–F7217–00 PARAFUSO 1 1
11 90506–20818 MOLA DE TENSAO 1 1
12 B6H–F247B–00 MANGUEIRA 2 1 1
13 54P–F7114–00 LIMITADOR 1 1
14 B6H–F7481–00 ASSOALHO DO ESTRIBO ESQ. 1 1
17 90109–068B2 PARAFUSO 1 1
18 97702–50016 PARAFUSO 1 1
19 90183–05807 PORCA MOLA 3 3
21 B6H–F7488–00 ASSOALHO DO ESTRIBO DIR. 1 1
24 90109–068B2 PARAFUSO 1 1
25 97702–50016 PARAFUSO 1 1
26 90183–05807 PORCA MOLA 3 3
38
REF.
BNN1
BNN2
NO.
28 B3V–F172W–01 TAMPA 1 1
29 B3V–F171L–00–P2 MOLDURA DA TAMPA LATERAL 1 1 DPBMU
B3V–F171L–00–P4 MOLDURA DA TAMPA LATERAL 1 1 RSH
B3V–F171L–00–P5 MOLDURA DA TAMPA LATERAL 1 1 MDBNM4
B3V–F171L–00–P6 MOLDURA DA TAMPA LATERAL 1 1 MNM3
30 97702–50016 PARAFUSO 3 3
31 B3V–F171M–00–P2 MOLDURA DA TAMPA LATERAL 2 1 DPBMU
B3V–F171M–00–P4 MOLDURA DA TAMPA LATERAL 2 1 RSH
B3V–F171M–00–P5 MOLDURA DA TAMPA LATERAL 2 1 MDBNM4
B3V–F171M–00–P6 MOLDURA DA TAMPA LATERAL 2 1 MNM3
32 97702–50016 PARAFUSO 3 3
33 B6H–F8385–01 TAMPA INFERIOR 1 1
34 90269–06816 REBITE 8 8
35 B3V–F7483–00 TAPETE ESQUERDO 1 1
36 B3V–F7484–00 TAPETE DIREITO 1 1
37 B3V–F7493–00 TAPETE 3 1 1
38 B3V–F7494–00 TAPETE 4 1 1
39 B3V–F741L–00 SUPORTE DO ESTRIBO ESQ. 1 1
40 BDC–F7431–00 ESTRIBO TRASEIRO 1 1 1
41 91402–20012 CONTRAPINO 1 1
42 91702–06038 PINO 1 1
44 93501–04830 ESFERA 1 1
45 90387–064H8 ESPACADOR 1 1
46 2DP–F7437–01 ARRUELA ESPECIAL 1 1
48 B3V–F742L–00 SUPORTE DO ESTRIBO DIR. 1 1
39
REF.
BNN1
BNN2
NO.
49 BDC–F7441–00 ESTRIBO TRASEIRO 2 1 1
50 91402–20012 CONTRAPINO 1 1
51 91702–06038 PINO 1 1
53 93501–04830 ESFERA 1 1
54 90387–064H8 ESPACADOR 1 1
55 2DP–F7437–01 ARRUELA ESPECIAL 1 1
40
FIG. 28 PROTETOR DE PERNA
REF.
BNN1
BNN2
NO.
1 B3V–F286F–00–P2 TAMPA FRONTAL 2 1 DPBMU
B3V–F286F–00–P5 TAMPA FRONTAL 2 1 RSH
B3V–F286F–00–P6 TAMPA FRONTAL 2 1 MDBNM4
B3V–F286F–00–P7 TAMPA FRONTAL 2 1 MNM3
2 90269–06816 REBITE 2 2
3 B3V–F8351–00–P2 CARENAGEM 1 DPBMU
B3V–F8351–00–P5 CARENAGEM 1 RSH
B3V–F8351–00–P6 CARENAGEM 1 MDBNM4
B3V–F8351–00–P7 CARENAGEM 1 MNM3
4 90183–05807 PORCA MOLA 1 1
5 97702–50016 PARAFUSO 2 2
6 B3V–F8377–00–P2 CARENAGEM 2 1 DPBMU
B3V–F8377–00–P5 CARENAGEM 2 1 RSH
B3V–F8377–00–P6 CARENAGEM 2 1 MDBNM4
B3V–F8377–00–P7 CARENAGEM 2 1 MNM3
7 90183–05807 PORCA MOLA 1 1
8 97702–50016 PARAFUSO 2 2
9 B6H–F835U–00 PAINEL 1 1 1
10 90183–05807 PORCA MOLA 7 7
11 90160–05009 PARAFUSO 1 1
12 B6H–F835V–00 PAINEL 2 1 1
13 90183–05807 PORCA MOLA 7 7
14 90160–05009 PARAFUSO 1 1
15 90464–16808 BRACADEIRA 2 2
16 B6H–F8311–00 PROTETOR DE PERNA 1 1 1
18 90387–07391 ESPACADOR 1 1
41
REF.
BNN1
BNN2
NO.
19 90183–05807 PORCA MOLA 8 8
20 B6H–F836K–00 PAINEL INTERNO 1 1 1
21 97702–50016 PARAFUSO 4 4
22 B6H–F177E–00 TAMPA 1 1
23 90183–05807 PORCA MOLA 2 2
24 B6H–F8321–00 SUPORTE 1 1 1
25 B6H–F838K–01 CAIXA 1 1 1
26 97702–50016 PARAFUSO 4 4
27 B6H–F838M–00 VEDACAO DA CAIXA 1 1 1
28 97707–50012 PARAFUSO 2 2
30 B6H–F1796–01 DOBRADICA 1 1
31 97702–50016 PARAFUSO 2 2
32 B6H–F836X–00 BOTAO, 1 1 1
33 90508–12800 MOLA DE TORCAO 1 1
34 90249–03017 PINO 1 1
36 B3V–F8312–00–P0 PROTETOR DE PERNA 2 1 1 MNM3
37 90269–06816 REBITE 2 2
38 B6H–F842M–00 TAMPA 1 1 1
39 97702–50016 PARAFUSO 4 4
40 B6H–F74A8–00 TAMPA DO COMBUSTIVEL 1 1
41 90183–05807 PORCA MOLA 1 1
42 B6H–F7426–00 MOLA DE RETORNO 1 1
43 B6H–F4494–10 CHICOTE 1 1
44 B6H–F839K–01 TAMPA 1 1 1
45 B6H–F131C–00 BARRA TRAVA 1 1
42
REF.
BNN1
BNN2
NO.
46 B6H–F7456–00 MOLA DE RETORNO 1 1
47 97707–50012 PARAFUSO 1 1
48 90338–07018 TAMPAO 2 2
49 B3V–F1568–00 ETIQUETA ADVERTENCIA 1 1
50 2DP–F413B–00 EMBLEMA 2 2
51 BNN–F8391–00 GRAFICO 1 1
52 BNN–F8392–00 GRAFICO 2 1
43
FIG. 29 PARABRISA
REF.
BNN1
BNN2
NO.
1 B1T–F61AA–00 PARABISA 1 1
2 90150–05008 PARAFUSO 4 4
4 B3V–H3559–00–P0 CAPA DO MEDIDOR 1 1 MNM3
5 90183–05807 PORCA MOLA 2 2
7 B6H–F837L–00 PAINEL DO CONSOLE 1 1 1
9 90464–16808 BRACADEIRA 1 1
10 90269–06816 REBITE 2 2
11 90109–068B2 PARAFUSO 2 2
12 97702–50016 PARAFUSO 6 6
13 90160–05009 PARAFUSO 2 2
14 90183–05807 PORCA MOLA 1 1
15 B6H–F8428–00 VEDACAO 1 2 2
16 B6H–F837M–00 PAINEL DO CONSOLE 2 1 1
17 90183–05807 PORCA MOLA 2 2
18 90160–05009 PARAFUSO 2 2
19 B6H–F8428–00 VEDACAO 1 1 1
20 B3V–F2865–00–P2 TAMPA FRONTAL 1 DPBMU
B3V–F2865–00–P5 TAMPA FRONTAL 1 RSH
B3V–F2865–00–P6 TAMPA FRONTAL 1 MDBNM4
B3V–F2865–00–P7 TAMPA FRONTAL 1 MNM3
21 90183–05807 PORCA MOLA 2 2
22 97702–50016 PARAFUSO 2 2
44
FIG. 30 GERADOR
REF.
BNN1
BNN2
NO.
1 B6H–H1450–00 ROTOR DO MAGNETO CONJ. 1 1
2 B6H–H1410–00 ESTATOR CONJ. 1 1
4 90201–12688 ARRUELA PLANA 1 1
5 90179–12004 PORCA 1 1
45
FIG. 31 PISCAS 1
REF.
BNN1
BNN2
NO.
1 B6H–H3310–01 PISCA DIANTEIRO CONJ. 1 1 1
2 2CB–H3311–00 .LAMPADA DO PISCA (12V-10W) 1 1
3 B6H–H3312–00 .LENTE DO PISCA 1 1
4 B6H–H4723–00 .GAXETA DA LENTE 1 1
5 B6H–H4140–01 .SOQUETE DA LAMPADA 1 1
6 97702–50014 PARAFUSO 3 3
7 97707–50016 PARAFUSO 1 1
8 B6H–H3320–01 PISCA DIANTEIRO CONJ. 2 1 1
10 B6H–H3322–00 .LENTE DO PISCA DIREITO 1 1
11 B6H–H4723–00 .GAXETA DA LENTE 1 1
12 B6H–H4150–01 .SOQUETE DA LAMPADA 2 1 1
13 97702–50014 PARAFUSO 3 3
14 97707–50016 PARAFUSO 1 1
46
FIG. 32 MEDIDOR
REF.
BNN1
BNN2
NO.
1 B6Y–H3510–23 VELOCIMETRO CONJUNTO 1 1
2 B6H–H3511–02 .LENTE DO VELOCIMETRO 1 1
3 97707–30014 .PARAFUSO 6 6
4 B6H–H3572–03 .CAIXA INFERIOR DO MEDIDOR 1 1
5 97702–30016 .PARAFUSO 5 5
6 97702–50016 PARAFUSO 2 2
47
FIG. 33 FAROL DIANTEIRO
REF.
BNN1
BNN2
NO.
1 B6H–H4300–10 FAROL COMPLETO 1 1
2 90480–13018 .ILHO DE BORRACHA 2 2
3 50C–F6326–00 .ILHO 4 4
4 90183–05807 .PORCA MOLA 2 2
6 90201–06828 ARRUELA PLANA 2 2
7 97702–50016 PARAFUSO 6 6
48
FIG. 34 LANTERNA TRASEIRA
REF.
BNN1
BNN2
NO.
1 B6H–H4710–00 LANTERNA TRASEIRA COMPLETA 1 1
3 90183–05807 .PORCA MOLA 4 4
4 90183–06818 .PORCA MOLA 2 2
5 90109–068B2 PARAFUSO 2 2
7 90387–068T3 ESPACADOR 2 2
49
FIG. 35 INTERRUP. DO GUIDAO E MANETE 1
REF.
BNN1
BNN2
NO.
1 B6H–H3972–00 INTERRUPTOR DO GUIDAO 4 1 1
2 98507–05025 .PARAFUSO 2 2
3 B3F–H3973–01 INTERRUPTOR DO GUIDAO 3 1 1
4 98507–05025 .PARAFUSO 2 2
50
FIG. 36 SISTEMA ELETRICO 1
REF.
BNN1
BNN2
NO.
1 18D–H2100–03 BATERIA CONJ. (12V 5AH) HTZ6 1 1
2 B6H–H2501–01 TRAVA DE DIRECAO, INTERRUPTOR 1 1
3 B6H–H276E–00 BOTAO COMPLETO 1 1
4 90109–068D5 PARAFUSO 2 2
5 90464–09806 BRACADEIRA 2 2
6 B6H–H2568–01 CAPA DA IGNICAO 1 1
7 BNN–H2590–00 CHICOTE PRINCIPAL COMPLETO 1 1
8 BC5–H2151–20 .FUSIVEL (2A) 3 3
9 BC5–H2151–00 .FUSIVEL (7.5A) 6 6
10 BNN–H2151–90 .FUSIVEL (5A) 2 2
11 1ST–H2151–10 .FUSIVEL (30A) 3 3
12 BC5–H2151–10 .FUSIVEL (30A) 2 2
14 90464–16808 BRACADEIRA 2 2
15 90464–30001 BRACADEIRA 2 2
16 90464–65801 BRACADEIRA 1 1
17 B8A–H2566–00 INTERRUPTOR CAVALETE LATERAL 1 1
18 90464–07805 BRACADEIRA 1 1
19 90464–13249 BRACADEIRA 2 2
21 BK6–H1950–00 RELE CONJUNTO 1 1
22 B3F–H1950–10 RELE CONJUNTO 1 1
23 1TP–81950–00 RELE CONJUNTO (1TP-00) 1 1
24 BX9–H252U–00 CAPA 1 1
25 B6H–H254B–00 TERMINAL COMPLETO 1 1
26 BJJ–H6260–50 UNIDAD DE CONTROLE REMOTO CONJ 1 1
27 B2T–H6261–03 .CHAVE REMOTA (SEM CODIFICACAO) 2 2
51
REF.
BNN1
BNN2
NO.
28 B3V–H5546–00 CINTA 1 1
29 B3F–H3383–00 ALARME 1 1
30 97702–50016 PARAFUSO 1 1
52
REF.
BNN1
BNN2
NO.
1 BNN–H594A–00 UNIDADE DE CONTROLE CONJUNTO 1 1
3 B6H–H2310–01 BOBINA DE IGNICAO CONJ. 1 1
4 90464–14809 BRACADEIRA 1 1
5 BK6–H2370–00 CACHIMBO DA VELA CONJ. 1 1
7 BBR–H592A–00 SENSOR DE O2 1 1
8 BK6–H6110–10 SOLENOIDE 1 1
9 BK6–H1847–00 .ANEL DE BORRACHA 1 1
11 2DP–H1861–00 GAXETA 1 1
12 52B–H3591–00 UNIDADE TERMOSTATICA 1 1
13 90430–10806 GAXETA 1 1
14 B6H–E5142–00 GUIA 1 1 1
16 B6H–E5143–00 GUIA 1 1
18 B3V–H3371–00 BUZINA 1 1
20 54P–H5130–00 REFLETOR TRASEIRO CONJ. 1 1
21 B6H–H4740–10 LUZ DA LICENCA CONJUNTO 1 1
22 2ND–H4744–00 .LAMPADA (12V-5W) 1 1
23 1CK–H4726–00 .PARAFUSO 2 2
24 98907–04014 PARAFUSO 1 1
25 90183–04039 PORCA MOLA 1 1
26 2FC–H5111–00 REFLETOR FRONTAL 1 2 2
27 95707–05500 PORCA FLANGE 2 2
53
REF.
BNN1
BNN2
NO.
1 B6H–H5970–00 SENSOR DA RODA DIANT. CONJ. 1 1
3 90464–14803 BRACADEIRA 7 7
4 B6H–H5930–08 UNIDADE HIDRAULICA CONJ. 1 1
5 B6H–H5980–00 SENSOR DA RODA TRAS. CONJ. 1 1
7 B6Y–H5810–04 UNIDADE CONTROLE COMUNICACAO 1 1
8 B6Y–H5546–00 CINTA 1 1
54
ÍNDICE NUMÉRICO
REF. REF. REF. REF. REF. REF.

No. PEÇA No. PEÇA No. PEÇA No. PEÇA No. PEÇA No. PEÇA
NO. NO. NO. NO. NO. NO.
52S–12439–00 6 – 2 2DP–E2279–00 3 – 12 B74–E4449–00 8 – 30 B74–E7664–00 12 – 14 B3V–F171X–00 16 – 11 B65–F3123–00 18 – 48

3Y6–23114–00 18 – 14 B6H–E2280–10 4 – 4 B6H–E4451–00 8 – 24 2DP–E7668–00 12 – 18 B3V–F1721–00–P2 16 – 5 2DP–F3126–00 18 – 2
18 – 30 2DP–E2288–00 4 – 5 B6H–E4452–10 8 – 25 BBP–E7670–00 12 – 11 B3V–F1721–00–P5 16 – 5 B6H–F312G–00 18 – 47
2K5–23152–00 18 – 8 B63–E22A2–00 6 – 6 B6H–E4453–00 8 – 23 B6H–E7674–00 12 – 5 B3V–F1721–00–P6 16 – 5 2DP–F3136–00 18 – 18
18 – 24 B6H–E240A–01 6 – 4 2DP–E4613–00 9 – 4 B63–E7674–10 12 – 15 B3V–F1721–00–P7 16 – 5 B6H–F3141–00 18 – 13
1TP–81950–00 36 – 23 2DP–E2410–00 6 – 1 BNN–E4711–10 9 – 1 B6H–E7678–00 12 – 19 B3V–F172W–01 27 – 28 18 – 29
BBB–E1102–00 1 – 1 B6H–E2422–00 5 – 1 B3V–E4718–00 9 – 2 2DP–E7678–10 12 – 21 B3V–F1731–00–P0 16 – 18 3HB–F3144–00 18 – 5
2DP–E111F–00 3 – 18 B63–E2439–00 6 – 7 B6H–E5142–00 37 – 14 BBP–E7683–00 12 – 16 B3V–F1731–00–P2 16 – 18 18 – 21
2DP–E1133–10 1 – 2 B6H–E2439–00 5 – 3 B6H–E5143–00 37 – 16 2DP–E7684–00 12 – 17 40D–F1737–00 25 – 26 3HB–F3145–00 18 – 3
B3V–E1165–00 1 – 8 B6H–E2450–00 5 – 5 B6H–E5150–00 10 – 1 BAL–E8179–00 6 – 29 B55–F1737–00 25 – 27 18 – 19
B6H–E1166–00 8 – 35 B65–E2462–02 6 – 5 B6H–E5316–00 11 – 14 BNN–F1110–01 14 – 1 B6H–F173B–00 16 – 34 2DP–F3153–00 18 – 16
2DP–E1169–00 1 – 9 BBB–E2467–00 6 – 25 B6H–E5326–00 11 – 15 B55–F111F–00 20 – 44 B6H–F173B–50 16 – 34 18 – 32
2DP–E1181–00 1 – 21 B6H–E2481–10 6 – 17 B6H–E533C–00 11 – 20 B55–F111M–00 14 – 28 BNN–F173L–00 16 – 35 3V3–F3156–00 18 – 4
B6H–E1185–00 5 – 4 B6H–E2482–00 6 – 18 B6H–E533E–00 11 – 22 B65–F113B–00 14 – 9 B3V–F1741–00–P0 16 – 21 18 – 20
2DP–E1191–00 1 – 7 B6H–E2483–00 6 – 19 54P–E5351–01 7 – 3 B3V–F117G–00 14 – 6 B3V–F1741–00–P2 16 – 21 2DP–F3157–00 18 – 9
B3F–E1193–00 1 – 15 B6H–E2491–00 6 – 20 B55–E5362–00 10 – 14 B3V–F117K–00 15 – 13 B6H–F1746–00 16 – 25 18 – 25
B6H–E1311–00 1 – 25 B65–E2611–00 6 – 27 5LW–E5363–00 10 – 16 B1S–F118K–00 20 – 46 BNN–F174G–00 16 – 37 2BU–F3158–00 18 – 11
2DP–E132G–00 1 – 13 5ST–E2615–00 6 – 9 B6H–E5371–00 10 – 29 B6H–F131C–00 28 – 45 BNN–F174H–00 16 – 38 18 – 27
B6H–E1351–00 1 – 26 B6H–E2621–01 6 – 21 5LW–E5371–01 11 – 5 5TP–F139X–00 19 – 20 BNN–F174L–00 16 – 36 2DP–F3170–00 18 – 7
2DP–E1391–00 1 – 18 5ST–E2843–00 6 – 10 B6H–E5373–00 10 – 30 B6H–F1410–00 14 – 5 B6H–F177E–00 28 – 22 18 – 23
2DP–E1392–00 1 – 19 B63–E2843–00 6 – 8 B6H–E5407–00 11 – 11 B55–F1511–00–P2 15 – 1 5HH–F178A–00 20 – 45 2DP–F3173–00 18 – 10
B6H–E1400–40 2 – 1 B6H–E3300–01 7 – 1 B6H–E5411–01 11 – 1 B55–F1511–00–P3 15 – 1 B6H–F1796–01 28 – 30 18 – 26
B63–E1603–00 2 – 9 54P–E3411–00 7 – 4 B6H–E5421–00 10 – 24 B55–F1511–00–P7 15 – 1 B6H–F1816–10 16 – 29 278–F3181–50 18 – 12
BK6–E1631–00 2 – 6 2DP–E3556–00 8 – 12 B65–E5423–01 10 – 18 B55–F1511–00–P8 15 – 1 B6H–F1817–10 16 – 31 18 – 28
2DP–E1633–00 2 – 7 B6H–E3585–00 8 – 1 B6H–E5431–00 11 – 8 B6H–F1552–01 15 – 4 B65–F1871–00 16 – 24 B6H–F3340–00 18 – 33
2DP–E1651–00 2 – 4 B3V–E3750–01 8 – 13 B6H–E5451–00 11 – 2 B3V–F1568–00 28 – 49 1S7–F1875–01 16 – 28 5YW–F3346–10 18 – 35
B63–E1681–00 2 – 2 BB8–E3761–10 8 – 6 B6H–E5461–10 10 – 25 BC5–F1578–01 15 – 16 B6H–F194U–00 26 – 46 4FP–F3411–10 18 – 38
BK6–E2111–00 3 – 1 5LW–E3769–00 10 – 15 B65–E5472–00 11 – 10 B6H–F1611–20 15 – 6 B55–F2117–00 17 – 6 4RT–F3411–10 18 – 40
BB8–E2113–01 3 – 4 BB8–E3770–10 8 – 5 2DP–E5474–00 11 – 13 B3V–F1621–00 20 – 35 B3V–F2141–00 14 – 10 1KL–F3412–10 18 – 36
2DP–E2117–00 3 – 6 B6H–E3907–01 19 – 5 B63–E5481–00 11 – 12 B6H–F162R–01 15 – 9 B6H–F2171–10 17 – 1 4RT–F3412–10 18 – 39
5TL–E2118–00 3 – 5 54P–E3915–00 19 – 6 B3V–E5495–00 11 – 9 B3V–F1651–00–P2 16 – 15 BBB–F2210–00 17 – 14 B3V–F3415–00 18 – 43
54P–E2119–00 3 – 3 54P–E3938–00 8 – 9 2DP–E5744–00 12 – 20 B3V–F1651–00–P5 16 – 15 B6H–F247A–00 27 – 6 B3V–F3416–00 18 – 42
B3F–E2121–00 3 – 2 B6H–E3971–00 19 – 4 B65–E6111–01 13 – 9 B3V–F1651–00–P6 16 – 15 B6H–F247B–00 27 – 12 1SK–F3418–00 18 – 46
50C–E2126–00 3 – 7 54P–E4137–00 8 – 10 BBP–E6611–00 12 – 22 B3V–F1651–00–P7 16 – 15 B6H–F247C–00 20 – 19 1P6–F341E–10 18 – 41
B55–E2150–01 3 – 8 B6H–E4146–00 8 – 4 BBP–E6620–00 12 – 7 B55–F1668–01 20 – 43 B3V–F2865–00–P2 29 – 20 5VL–F341E–10 18 – 37
45P–E2156–00 3 – 16 54P–E4147–00 8 – 7 B65–E6626–00 12 – 9 B3V–F1711–00–P2 16 – 1 B3V–F2865–00–P5 29 – 20 B63–F3462–00 18 – 34
5YP–E2157–01 4 – 6 5CA–E4147–00 8 – 8 2DP–E7211–01 13 – 4 B3V–F1711–00–P5 16 – 1 B3V–F2865–00–P6 29 – 20 B6H–F4110–01 19 – 1
33S–E2159–01 3 – 9 54P–E416A–00 8 – 17 2DP–E7410–02 13 – 1 B3V–F1711–00–P6 16 – 1 B3V–F2865–00–P7 29 – 20 2DP–F413B–00 28 – 50
3 – 14 B6H–E4199–00 8 – 2 B6H–E7421–00 13 – 3 B3V–F1711–00–P7 16 – 1 B3V–F286F–00–P2 28 – 1 B3V–F414A–01 19 – 12
B6H–E2160–00 3 – 13 54P–E4243–00 8 – 15 2DP–E7465–00 12 – 12 B3V–F171E–00 16 – 9 B3V–F286F–00–P5 28 – 1 5D9–F414G–00 14 – 4
BBR–E2170–00 4 – 1 54P–E4335–00 8 – 16 2DP–E7465–10 12 – 13 B3V–F171L–00–P2 27 – 29 B3V–F286F–00–P6 28 – 1 15 – 2
2PV–E2210–01 4 – 11 B6H–E4411–10 8 – 20 B55–E7611–00 12 – 6 B3V–F171L–00–P4 27 – 29 B3V–F286F–00–P7 28 – 1 19 – 19
B6H–E2213–00 4 – 12 B6H–E4412–10 8 – 21 B3V–E7620–10 12 – 1 B3V–F171L–00–P5 27 – 29 B6H–F3102–00 18 – 1 54P–F414G–10 19 – 8
B6H–E2223–00 5 – 2 B6H–E4435–00 8 – 31 2DP–E7623–00 12 – 3 B3V–F171L–00–P6 27 – 29 B6H–F3103–00 18 – 17 B6H–F419A–10 19 – 16
BB8–E2226–00 3 – 11 B6H–E4437–00 8 – 22 BBP–E7632–00 12 – 2 B3V–F171M–00–P2 27 – 31 2DP–F3110–00 18 – 6 B3V–F4217–00 19 – 13
1DB–E2228–00 4 – 10 4ST–E443E–00 11 – 6 B8R–E7641–00 12 – 23 B3V–F171M–00–P4 27 – 31 18 – 22 B6H–F4318–01 19 – 14
B65–E2231–00 4 – 8 5TL–E443E–00 8 – 27 44D–E7653–00 12 – 4 B3V–F171M–00–P5 27 – 31 2DP–F3111–00 18 – 15 B6H–F4491–00 19 – 9
B6H–E2241–00 4 – 9 B5D–E443G–00 8 – 28 B6H–E7660–00 12 – 10 B3V–F171M–00–P6 27 – 31 18 – 31 B6H–F4494–10 28 – 43
55
ÍNDICE NUMÉRICO

B6H–F4610–01 19 – 11 5HV–F585B–10 26 – 4 44D–F7114–00 14 – 14 BNN–F8392–00 28 – 52 B6H–H3980–00 26 – 12 90109–08232 24 – 2

B5D–F465B–00 15 – 11 26 – 24 54P–F7114–00 27 – 4 B6H–F839K–01 28 – 44 B6H–H4140–01 31 – 5 90110–06378 1 – 24
B65–F465E–00 15 – 12 2DP–F5867–00 26 – 30 27 – 13 B6H–F8428–00 29 – 15 B6H–H4150–01 31 – 12 90110–06846 8 – 19
B6H–F470F–01 20 – 2 2DP–F5867–10 26 – 10 54P–F7121–00 10 – 3 29 – 19 B6H–H4300–10 33 – 1 90110–06880 30 – 3
BDC–F4727–00 20 – 16 B6H–F5872–00 26 – 15 B65–F7217–00 27 – 9 B6H–F842M–00 28 – 38 B6H–H4710–00 34 – 1 90110–06881 36 – 20
B6H–F472A–00 20 – 18 B6H–F5873–00 26 – 18 1LB–F7254–00 27 – 7 B6H–F842N–00 20 – 37 B3V–H4716–00 16 – 13 90111–05816 20 – 38
B6H–F472T–01 20 – 25 B6H–F5874–00 26 – 34 B3V–F7311–01 27 – 8 B6H–H1410–00 30 – 2 B6H–H4723–00 31 – 4 90111–06860 9 – 3
B6H–F4730–01 20 – 1 B6H–F5875–00 18 – 49 B3V–F741L–00 27 – 39 B6H–H1450–00 30 – 1 31 – 11 90119–06212 20 – 20
B6Y–F473R–00 20 – 7 B6H–F5876–00 18 – 51 B6H–F7426–00 28 – 42 BK6–H1847–00 37 – 9 1CK–H4726–00 37 – 23 90119–06235 27 – 16
3C1–F4741–00 20 – 4 B6H–F587A–00 26 – 48 B3V–F742L–00 27 – 48 2DP–H1861–00 37 – 11 B6H–H4740–10 37 – 21 27 – 23
5BP–F4741–00 20 – 3 B6H–F5886–00 17 – 11 BDC–F7431–00 27 – 40 BK6–H1950–00 36 – 21 2ND–H4744–00 37 – 22 90119–068B7 19 – 2
B6H–F475M–00 20 – 5 BNN–F5887–00 26 – 42 2DP–F7437–01 27 – 46 B3F–H1950–10 36 – 22 2FC–H5111–00 37 – 26 90149–05030 21 – 6
1S7–F4768–00 20 – 24 B3V–F588F–00 14 – 26 27 – 55 18D–H2100–03 36 – 1 54P–H5130–00 37 – 20 23 – 3
B6H–F4769–00 20 – 12 B6H–F588G–10 17 – 8 BDC–F7441–00 27 – 49 B6H–H2129–11 20 – 33 B3V–H5546–00 36 – 28 90149–05801 1 – 10
B6H–F4773–10 20 – 27 2DP–F589F–00 26 – 8 B6H–F7456–00 28 – 46 BC5–H2151–00 36 – 9 B6Y–H5546–00 38 – 8 90149–06104 25 – 21
B65–F4780–00 20 – 22 26 – 28 B6H–F7481–00 27 – 14 1ST–H2151–10 36 – 11 BK6–H5752–00 19 – 7 90149–10805 22 – 16
B6H–F478E–10 20 – 21 2R6–F5916–00 22 – 14 B3V–F7483–00 27 – 35 BC5–H2151–10 36 – 12 B63–H5801–01 8 – 18 90150–05008 29 – 2
B6H–F479D–00 20 – 39 24 – 14 B3V–F7484–00 27 – 36 BC5–H2151–20 36 – 8 B6Y–H5810–04 38 – 7 90159–05032 25 – 24
B6H–F4811–00 20 – 14 2BM–F5917–00 22 – 6 B6H–F7488–00 27 – 21 BNN–H2151–90 36 – 10 BBR–H592A–00 37 – 7 90159–06817 33 – 5
B6H–F5168–00–33 21 – 1 5YP–F5917–00 24 – 6 B3V–F7493–00 27 – 37 B6H–H2310–01 37 – 3 B6H–H5930–08 38 – 4 90160–05009 28 – 11
B6H–F5168–00–P3 21 – 1 2BM–F5919–00 22 – 11 B3V–F7494–00 27 – 38 BK6–H2370–00 37 – 5 BNN–H594A–00 37 – 1 28 – 14
2DP–F517G–00 21 – 5 5P0–F5919–01 24 – 11 B6H–F74A8–00 28 – 40 B6H–H2501–01 36 – 2 B6H–H5970–00 38 – 1 29 – 13
23 – 2 2DP–F5920–00 22 – 13 2DP–F814F–00 20 – 40 B3V–H251P–00 14 – 2 B6H–H5980–00 38 – 5 29 – 18
B55–F5181–00 21 – 10 2DP–F5920–50 24 – 13 3AY–F8152–00 20 – 41 BX9–H252U–00 36 – 24 BK6–H6110–10 37 – 8 90160–05014 25 – 25
B6H–F5338–00–33 23 – 1 5YP–F5924–00 22 – 12 BNN–F8199–W0 20 – 42 B6H–H2530–00 26 – 32 BJJ–H6260–50 36 – 26 90160–05810 16 – 19
B6H–F5338–00–P3 23 – 1 24 – 12 B6H–F8311–00 28 – 16 B6H–H254B–00 36 – 25 B2T–H6261–03 36 – 27 16 – 22
BAL–F5522–00 26 – 44 5YP–F5925–01 22 – 10 B3V–F8312–00–P0 28 – 36 B8A–H2566–00 36 – 17 4C9–W0048–00 22 – 8 90170–05803 3 – 10
2BM–F5802–00 22 – 4 24 – 10 B6H–F8321–00 28 – 24 B6H–H2568–01 36 – 6 24 – 8 3 – 15
5P0–F5802–00 24 – 4 5YP–F5937–00 22 – 7 B3V–F8351–00–P2 28 – 3 BNN–H2590–00 36 – 7 B65–WE662–00 12 – 8 90170–08810 1 – 16
5YP–F5803–50 22 – 5 24 – 7 B3V–F8351–00–P5 28 – 3 B6H–H276E–00 36 – 3 90105–068C5 14 – 24 90170–12802 12 – 27
24 – 5 B6H–F6110–01 25 – 1 B3V–F8351–00–P6 28 – 3 B6H–H3310–01 31 – 1 90105–088E3 14 – 16 90179–05003 14 – 20
2DP–F5805–00 22 – 9 B6H–F6143–00 25 – 16 B3V–F8351–00–P7 28 – 3 2CB–H3311–00 31 – 2 90105–088E8 17 – 15 90179–12004 12 – 26
B6H–F5805–00 24 – 9 B3V–F6144–00 25 – 22 B6H–F8356–00 14 – 18 31 – 9 90105–10283 14 – 12 30 – 5
2DP–F5807–00 26 – 2 4US–F6199–00 20 – 11 B6H–F835U–00 28 – 9 34 – 2 90105–108B0 25 – 2 90179–25810 18 – 44
2DP–F5807–10 26 – 22 B1T–F61AA–00 29 – 1 B6H–F835V–00 28 – 12 B6H–H3312–00 31 – 3 90105–108C1 17 – 16 90183–04039 37 – 25
B6H–F580U–00 22 – 3 B3V–F6219–00–P0 25 – 19 B6H–F8368–00 25 – 28 B6H–H3320–01 31 – 8 90109–068A4 15 – 3 90183–05807 16 – 2
B6H–F580W–00 24 – 3 B3V–F6240–00 25 – 4 B6H–F836K–00 28 – 20 B6H–H3322–00 31 – 10 90109–068B2 15 – 7 16 – 6
B6H–F581J–10 26 – 38 B01–F6241–00 25 – 5 B6H–F836X–00 28 – 32 B3V–H3371–00 37 – 18 16 – 26 20 – 10
5P0–F5827–00 24 – 15 2PH–F6246–00 25 – 6 B3V–F8377–00–P2 28 – 6 B3F–H3383–00 36 – 29 20 – 9 27 – 19
B8A–F5827–00 22 – 15 B6H–F6257–10 26 – 14 B3V–F8377–00–P5 28 – 6 B6Y–H3510–23 32 – 1 27 – 17 27 – 26
2DP–F582U–00 22 – 1 2DP–F6280–10 25 – 7 B3V–F8377–00–P6 28 – 6 B6H–H3511–02 32 – 2 27 – 24 28 – 4
2DP–F582W–00 24 – 1 2DP–F6290–10 25 – 8 B3V–F8377–00–P7 28 – 6 B3V–H3559–00–P0 29 – 4 29 – 11 28 – 7
B6H–F583T–00 26 – 1 B6H–F6301–10 25 – 9 B6H–F837L–00 29 – 7 B6H–H3572–03 32 – 4 34 – 5 28 – 10
B6H–F583V–00 26 – 21 50C–F6326–00 33 – 3 B6H–F837M–00 29 – 16 52B–H3591–00 37 – 12 90109–068C6 15 – 8 28 – 13
2DP–F5852–00 26 – 3 1S9–F6332–00 26 – 11 B6H–F8385–01 27 – 33 2DP–H3912–00 26 – 27 90109–068C7 15 – 8 28 – 19
26 – 23 26 – 31 B6H–F838K–01 28 – 25 2DP–H3922–00 26 – 7 90109–068D5 14 – 3 28 – 23
5HV–F5854–10 26 – 5 B6H–F7111–00 27 – 1 B6H–F838M–00 28 – 27 B6H–H3972–00 35 – 1 36 – 4 28 – 41
26 – 25 B6H–F7112–00 27 – 2 BNN–F8391–00 28 – 51 B3F–H3973–01 35 – 3 90109–08232 22 – 2 29 – 5
56
ÍNDICE NUMÉRICO

90183–05807 29 – 14 90387–08821 14 – 15 90467–10008 10 – 31 90520–40801 11 – 17 95602–06100 26 – 29 95E32–06030 10 – 23

29 – 17 90387–08823 6 – 11 90467–11106 11 – 7 90520–50801 11 – 19 95602–08200 14 – 17 95E32–06035 11 – 4
29 – 21 90387–08847 20 – 30 90467–11825 8 – 36 91312–05010 19 – 10 95602–10200 14 – 11 95E32–06045 5 – 13
33 – 4 90387–10277 21 – 9 10 – 32 25 – 12 14 – 13 95E32–06050 6 – 24
34 – 3 90387–10839 21 – 2 90467–12052 8 – 37 91312–05016 3 – 17 27 – 10 95E32–06060 10 – 7
90183–06815 16 – 10 90387–10857 14 – 8 90467–12809 8 – 29 91332–06025 8 – 3 95612–08618 1 – 6 95E32–06110 10 – 8
16 – 12 90387–10867 20 – 31 90467–19803 6 – 15 91402–20012 27 – 41 95702–06500 20 – 6 95E32–08020 27 – 47
90183–06818 15 – 15 90387–17807 17 – 5 6 – 16 27 – 50 95702–08500 9 – 5 27 – 56
25 – 17 90387–17808 17 – 9 90467–20806 6 – 14 91702–06038 27 – 42 95707–05500 37 – 27 95E32–08035 10 – 28
34 – 4 90388–08803 10 – 5 90468–08086 20 – 13 27 – 51 95812–10030 24 – 16 95E32–08045 10 – 27
90185–10011 25 – 3 17 – 2 90468–18121 20 – 17 92017–05016 25 – 11 95822–06016 34 – 6 95E37–06012 19 – 17
90185–10012 21 – 11 90388–10808 10 – 4 90480–01559 16 – 4 93102–08800 1 – 14 95D02–06012 18 – 50 37 – 15
90185–16800 23 – 6 90388–10818 14 – 7 16 – 8 93102–20815 13 – 11 18 – 52 37 – 17
90201–06828 33 – 6 90401–10812 26 – 16 27 – 15 93102–22829 10 – 9 26 – 43 97602–04312 26 – 13
90201–08859 1 – 17 26 – 19 27 – 22 93102–24802 10 – 19 37 – 19 26 – 33
90201–08884 20 – 29 26 – 35 90480–13018 33 – 2 93102–32807 13 – 8 95D32–06012 14 – 27 97702–30016 32 – 5
90201–10118 26 – 17 26 – 39 90480–14229 14 – 21 93106–20816 21 – 3 17 – 12 97702–50014 31 – 6
26 – 20 90430–06803 1 – 5 90480–14808 16 – 27 93106–28801 17 – 3 95D32–06016 6 – 28 31 – 13
26 – 36 1 – 28 90480–14825 28 – 17 93210–09805 4 – 2 37 – 10 97702–50016 15 – 10
26 – 40 5 – 9 90480–14833 6 – 12 93210–14816 10 – 17 38 – 2 16 – 17
90201–10831 21 – 12 90430–08804 10 – 13 90480–17802 14 – 25 93210–19809 5 – 14 38 – 6 27 – 18
90201–10853 17 – 17 90430–10806 37 – 13 90480–19802 20 – 32 93210–29800 7 – 6 95D32–06020 14 – 23 27 – 25
90201–12688 30 – 4 90430–12803 10 – 11 90501–12743 27 – 43 93210–39803 5 – 11 37 – 2 27 – 30
90201–15847 12 – 31 90450–43805 8 – 34 27 – 52 93211–28800 10 – 20 95D32–06025 28 – 35 27 – 32
90201–15849 12 – 25 90464–07014 26 – 37 90501–16004 7 – 5 93300–608X0 5 – 7 95D32–06030 6 – 13 28 – 5
90201–16819 12 – 24 90464–07018 16 – 16 90506–20818 27 – 11 93306–001X9 4 – 3 8 – 11 28 – 8
90202–26142 18 – 45 90464–07805 16 – 33 90506–23815 20 – 15 93306–254Y2 13 – 10 8 – 32 28 – 21
90249–03017 28 – 34 26 – 45 90506–40806 27 – 5 93306–255X2 13 – 7 95D32–08035 10 – 12 28 – 26
90269–06812 20 – 36 36 – 18 90508–12800 28 – 33 93306–300YN 21 – 4 20 – 28 28 – 31
90269–06816 15 – 5 90464–07807 25 – 15 90520–02014 25 – 20 93306–301XT 13 – 12 95D32–08050 14 – 19 28 – 39
16 – 3 90464–08009 25 – 10 90520–02849 25 – 18 93306–302YU 13 – 2 95D32–10045 9 – 6 29 – 12
16 – 7 90464–09806 36 – 5 27 – 20 93306–303YW 13 – 6 95D32–10060 9 – 7 29 – 22
20 – 26 90464–13249 36 – 19 27 – 27 93306–303YX 17 – 4 17 – 10 32 – 6
25 – 23 90464–14002 19 – 18 29 – 3 93310–528YK 2 – 3 95D37–06016 17 – 7 33 – 7
27 – 34 90464–14803 38 – 3 90520–02850 29 – 6 933A6–202Y0 12 – 28 95E32–06010 1 – 4 36 – 30
28 – 2 90464–14809 37 – 4 90520–04806 20 – 8 93450–16115 2 – 8 1 – 27 97707–30014 32 – 3
28 – 37 90464–16006 17 – 13 90520–06817 28 – 29 93501–04830 27 – 44 95E32–06012 20 – 23 97707–50012 20 – 34
29 – 10 90464–16808 25 – 13 90520–10851 11 – 18 27 – 53 26 – 47 28 – 28
90280–03017 2 – 5 26 – 41 90520–10853 6 – 22 93900–00824 21 – 8 26 – 49 28 – 47
90338–07018 28 – 48 28 – 15 90520–10854 16 – 20 23 – 5 36 – 13 97707–50016 16 – 14
90340–12813 1 – 3 29 – 9 90520–10855 6 – 23 94111–13805 21 – 7 95E32–06014 3 – 19 31 – 7
90340–12816 10 – 10 36 – 14 11 – 23 94113–13811 23 – 4 95E32–06020 4 – 13 31 – 14
90380–10800 12 – 29 90464–24230 25 – 14 90520–10856 11 – 16 94568–F9096 4 – 7 6 – 3 97707–50025 8 – 26
90387–064H8 27 – 45 90464–30001 16 – 30 90520–15803 19 – 3 94700–00415 1 – 20 6 – 26 98502–05020 7 – 2
27 – 54 19 – 15 90520–15816 8 – 33 95022–06020 15 – 14 10 – 22 98502–06012 8 – 14
90387–068N8 14 – 22 36 – 15 90520–15817 16 – 23 95027–06020 5 – 8 37 – 6 98507–05025 35 – 2
90387–068T3 34 – 7 90464–65801 36 – 16 90520–20800 29 – 8 95302–10600 17 – 18 95E32–06025 5 – 12 35 – 4
90387–07391 28 – 18 90467–08003 16 – 32 90520–40800 11 – 21 95602–06100 26 – 9 95E32–06030 1 – 11 98707–04012 26 – 6
57
ÍNDICE NUMÉRICO

98707–04012 26 – 26
98907–04014 37 – 24
99002–09600 27 – 3
99009–08400 5 – 6
99009–25400 13 – 5
99009–35700 12 – 30
99480–03012 10 – 2
99530–08012 1 – 12
5 – 10
99530–10114 1 – 22
1 – 23
10 – 6
10 – 21
10 – 26
11 – 3
58

NMAX160A Nmax160Ase: (BNN1) (BNN2)

Enviado por

Dados do documento

Título original

Direitos autorais

Formatos disponíveis

Compartilhar este documento

Compartilhar ou incorporar documento

Opções de compartilhamento

Você considera este documento útil?

Este conteúdo é inapropriado?

Direitos autorais:

Formatos disponíveis

NMAX160A Nmax160Ase: (BNN1) (BNN2)

Enviado por

Direitos autorais:

Formatos disponíveis

NMAX160A ( BNN1 )

NMAX160ASE ( BNN2 ) BRASIL

3. Peças componentes de conjuntos

No. PEÇA DESCRIÇÃO QTDE OBSERVAÇÕES

No. PEÇA DESCRIÇÃO QTDE OBSERVAÇÕES

No. de Série do Chassi No. de Série do Motor No. de Série do Chassi

No. Série Nome do Modelo Código do Modelo

No. de Série do Motor

No. Série Nome do Modelo Código do Modelo

2 2DP–E1133–10 .GUIA DA VALVULA 1 4 4

3 90340–12813 .TAMPAO DO DRENO 1 1

4 95E32–06010 PARAFUSO FLANGE 1 1

7 2DP–E1191–00 TAMPA, CABECOTE DO CILINDRO 1 1 1

8 B3V–E1165–00 PLACA DE RESPIRO 1 1

9 2DP–E1169–00 GAXETA DA TAMPA DO RESPIRO 1 1

11 95E32–06030 PARAFUSO FLANGE 4 4

12 99530–08012 PINO GUIA 2 2

14 93102–08800 RETENTOR DE OLEO 1 1

15 B3F–E1193–00 GAXETA DA TAMPA DO CABECOTE 1 1 1

17 90201–08859 ARRUELA PLANA 4 4

20 94700–00415 VELA DE IGNICAO (NGK CPR8EA) 1 1

21 2DP–E1181–00 GAXETA, CABECOTE DO CILINDRO 1 1 1

22 99530–10114 PINO GUIA 2 2

23 99530–10114 PINO GUIA 2 2

24 90110–06378 PARAFUSO HEXAGONAL INTERNO 2 2

26 B6H–E1351–00 GAXETA DO CILINDRO 1 1

27 95E32–06010 PARAFUSO FLANGE 1 1

2 B63–E1681–00 .PINO DO VIRABREQUIM 1 1 1

5 90280–03017 CHAVETA MEIA LUA 1 1

6 BK6–E1631–00 PISTAO (STD) 1 1

7 2DP–E1633–00 PINO DO PISTAO 1 1

8 93450–16115 ANEL TRAVA 2 2

9 B63–E1603–00 JOGO DE ANEIS (STD) 1 1

2 B3F–E2121–00 VALVULA DE ESCAPE 2 2

3 54P–E2119–00 RETENTOR DA HASTE DA VALVULA 4 4

4 BB8–E2113–01 MOLA INTERNA DA VALVULA 4 4

5 5TL–E2118–00 TRAVA DA VALVULA 8 8

6 2DP–E2117–00 ASSENTO SUPERIOR DA MOLA 4 4

7 50C–E2126–00 ASSENTO DA MOLA DA VALVULA 2 4 4

8 B55–E2150–01 BRACO DO BALANCIM DA VALVULA 1 1

9 33S–E2159–01 .PARAFUSO DE AJUSTE DA VALVULA 2 2

11 BB8–E2226–00 MOLA DO BRACO 1 1

12 2DP–E2279–00 PLACA DE FIXACAO 1 1

13 B6H–E2160–00 BRACO DO BALANCIM DA VALVULA 2 1 1

14 33S–E2159–01 .PARAFUSO DE AJUSTE DA VALVULA 2 2

16 45P–E2156–00 EIXO DO BALANCIM 2 2 2

17 91312–05016 PARAFUSO HEXAGONAL 2 2

18 2DP–E111F–00 PLACA DE FIXACAO 1 1

19 95E32–06014 PARAFUSO FLANGE 1 1

2 93210–09805 .ANEL DE BORRACHA 1 1

4 B6H–E2280–10 DESCOMPRESSOR COMPLETO 1 1

5 2DP–E2288–00 CAME DE DESCOMPRESSAO 1 1

7 94568–F9096 CORRENTE (DID SCR-0404 SV) 1 1

8 B65–E2231–00 GUIA LIMITADORA 1 1 1

9 B6H–E2241–00 GUIA LIMITADORA 2 1 1

11 2PV–E2210–01 TENSIONADOR DA CORRENTE CONJ. 1 1

12 B6H–E2213–00 GAXETA DA CAIXA DO TENSIONADOR 1 1

13 95E32–06020 PARAFUSO FLANGE 2 2

3 B6H–E2439–00 ANEL DE BORRACHA 1 1

4 B6H–E1185–00 TAMPA LATERAL DO CABECOTE 3 1 1

5 B6H–E2450–00 EIXO IMPULSOR COMPLETO 1 1

6 99009–08400 ANEL TRAVA 1 1

8 95027–06020 PARAFUSO FLANGE 3 3
