DeviceNet
Overview
(Confidential – For Internal Use Only)
Copyright © 2007 Rockwell Automation, Inc. All rights reserved.
1
Desktop PC
Gateway or Linking Device
Servo
Maintenance PC
Drive Controller
Micro PLC
Operator Interface
Motor Starter
From the Internet to DeviceNet

DeviceNet
Overview The Transition from Hardwired I/O to
Direct Network Connection is Underway
Control Network Device Network
T
I/O
509 -BOD
Smart I/O 24vdc
Rack Rack
D D RS232
A A D D A
device
1-5 vDC T
4-20 ma
120 vAC
509 -BOD
24vdc
24 vDC
Current/Future
Previous/Current Standards
Standards
(Confidential – For Internal Use Only) Copyright © 2007 Rockwell Automation, Inc. All rights reserved. 3
DeviceNet
Overview What is DeviceNet?
DeviceNet is a device level industrial network which allows direct

connection of field devices, such as switches, lights, drives, and valves
to the network. Connecting field devices directly to the network has
several major benefits:
– Reduced hardwiring
• decreases labor expenses
• in many cases reduces hardware costs
– Reduced start-up time
• minimizes miswiring
– Reduced down time due to enhanced diagnostics from each
device
• diagnostics provide predictive failure warnings
• diagnostics aid troubleshooting
DeviceNet
Overview DeviceNet Features
• Selectable data rates: 125, 250, 500 Kbaud

– Not required to support all
– Data rates trade speed for distances
• Designed primarily for communications directly to field devices
• A producer-consumer network that supports multiple masters,
and shared inputs
• Flexible installation options
– many cable and connector options
– Support for up to 64 nodes
• An open network represented by the Open DeviceNet Vendors
Association (ODVA)
• Node removal without severing trunk line and under power
• Protection from wiring errors. Reverse wiring protection circuitry
built into devices
DeviceNet
Overview Open DeviceNet Vendor Association (ODVA)
• Owns the DeviceNet technology

– Specifications
– Electronic Data Sheets (EDS)
– Trademark
• Over 300 member companies worldwide
– ABB, Allen-Bradley, AEG Schneider, ASCO/Joucomatic, Banner, Beldon, Cutler-
Hammer, Festo, Fischer-Rosemount, Hitachi, Intellution, Mitsubishi, Nematron,
Omron, Parker Hannifin, Pepperl+Fuchs, Reliance, SMC, Toshiba, Turck,
Wonderware, etc.
• Over 100 SI/OEM members
– Alvey, Jervis B. Webb, KR Automation, Rapistan Demag, ...
• Internet Home Page ((http://www.odva.org)
– On-line Product Catalog (over 275 products advertised)
– Newsletters/Current Events
– Member companies + contact names
– Specifications order form
DeviceNet
Overview
Media Details Media Details
Trunk
Node Node
Node Node max

Node
20 feet
Node
P/S
Node Node Node
Node Node
DeviceNet
Overview
Topology
DeviceNet is a Trunk/Drop or bus-based network. Nodes can be
connected to the trunk cable directly, or through a variety of taps and
terminals. Regardless of the connection method to the trunk, each node
must be within 20 feet of the trunk. Since DeviceNet is a bus-based
network, each end of a segment must be terminated. Terminators are 121
ohm.
Terminator Tap Terminator
Trunk
Node Node
Daisy Chain
Node Node max
Node
20 feet
Drop
Length Node
P/S
Node Node Node
Node Node
Branching Drop Zero Drop Short Drops
DeviceNet
Overview Topology
DeviceNet allows multiple devices to be connected to a single tap. You

can connect any number of devices to a single tap as long as the
following rules are followed:
• Each device must be within 20 feet of the trunk
• You are within the amount of total allowable drop cable
• You are within general network specs, such as node numbers and power
requirements
Multiple devices on a single tap
Node Node
Node Node max

Node
20 feet
Node
P/S
Node Node Node
Node Node
Branching Drop Zero Drop Short Drops

DeviceNet
Overview
Termination Resistors
• Termination resistors are 121 Ohms, 1/4 Watt, 1%

• They MUST be placed at each end of the trunk line between white
and blue wires.
• There are both open and sealed versions
• Do not use carbon resistors. Metal film is preferable
DeviceNet
Overview Power in the Cable
DeviceNet cables differ from ControlNet and Ethernet in that they not only
carry the network signal, but they also carry 24V DC power. This allows
the user to plug simple devices like photoeyes and pushbutton stations
directly to the network without having to bring in an external power
source.
DeviceNet uses two formats of cable: round and flat.
Round Cable Flat Cable

CAN_L Shield and drain CAN_H CAN_L
wire +24Vdc 0 Vdc
CAN_H +24Vdc
Red +24 Vdc White CAN_H

0 Vdc Black 0 Vdc Blue CAN_L
DeviceNet
Overview Network Grounding
• V- ( Black Wire ) and Shield ( Bare Wire ) MUST be connected to a good earth
ground at only one location on a DeviceNet System.
Signal
Signal
Shield ..
V-
V+ .
Power Tap
V-
. . V+ 24 VDC Power Supply
DeviceNet
Overview
Power in the Cable
Since devices get power from the network, there has to be a source of
power on the network. Multiple power supplies can be attached if
necessary. Power supplies are attached to the network using power
taps. The power supplies do not require a node number.
Trunk
Node Node
Node Node max

Node
20 feet
Node
P/S
Node Node Node
Node Node
Power supply
connected directly to
the network.
DeviceNet
Overview Single Supply Configuration
up to 500 m
up to 500 m up to 500 m
power
N32 N1 N33 N64
supply
• Characteristics and Advantages

– Power supplies can be located anywhere on the network
• Must consider IR losses along cable
– Greater current than most comparable networks
• Up to 8 amps (NEC limits to 4 amps)
– Power supplies are standard, low cost models
DeviceNet
Overview Multiple Supply Configuration
Optional
Second
24 V 24 V Supply
Power Power
Supply Supply
V+ Power Conductor
V- Power Conductor
Node Node Node Node
• Characteristics and Advantages

– Loads shared by supplies so same low cost supplies are used
– Substantially more current
• Still 8 amp limit on any branch of the trunk ( NEC limit of 4 Amps)
– Supplies can be located anywhere (consider IR losses)
DeviceNet
Overview Power Bus Capabilities
• Single & multiple supply configurations

• High current capability by using multiple power supplies.
• A change has been made to the policy, so that device output power can now be
wired to the DeviceNet network power supply. Consult the Cable Planning and
installation guide DN-6.7.2, May 1999, Appendix B for guidelines, before
attempting this. Remember that the output current must also be added into the
common mode calculations.
• DeviceNet specifications state that 24VDC power supplies must power up to full voltage
in no more than 250ms under full load and 7000uf capacitance. Failure of power supply
to follow this specification will cause devices to Bus Off (solid red network LED) when
AC is switched on to the power supply. If devices go Bus Off when AC is applied, cycle
DC power off then on at the supply and see if devices still Bus Off. If they don’t then
power supply is out of spec. If they still Bus Off, then you have other issues with your
network.
DeviceNet
Overview
DeviceNet Cable Highlights
Round Cable
Red +24VDC ( V+ )
White CAN-H
Bare Shield
Blue CAN-L
Black +0VDC ( V- )
• 5 Conductors, 1 pair for 24 Volts DC power, 1 pair

for CAN communication, 1 Shield
DeviceNet
Overview DeviceNet Thick Cable
Beldfoil Aluminum/Polyester Shield
Vinyl Jacket
0.480” O.D. Blue & White Data Pair
Polypropylene Fillers Datalene Insulation
18 AWG.
Tinned and Stranded
Copper Conductors
15 AWG.
65% Coverage Tinned and Stranded
Stranded Drain Wire
Tinned Copper Braid Shield Copper Conductors
Tinned Copper
18 AWG.
Red & Black DC Power Pair
PVC/Nylon Insulation
Thick Cable Belden Class Capacity (DC Amps)

Grey PVC 7897A 1 8
Grey PVC 3082A 2 4
Yellow CPE 3083A 2 4
DeviceNet
Overview DeviceNet Thin Cable
Beldfoil Aluminum/Polyester Shield
Vinyl or CPE Jacket Polypropylene Fillers

0.270” O.D. Blue & White Data Pair
Datalene Insulation
Overall Mylar Tape
24 AWG.
Tinned and Stranded
Copper Conductors
22 AWG.
Tinned and Stranded
Stranded Drain Wire
65% Coverage Copper Conductors
Tinned Copper
Tinned Copper Braid Shield
22 AWG.
Red & Black DC Power Pair
Thin Cable Belden AB number
PVC/Nylon Insulation
Grey PVC 3084A YR-29832
Yellow CPE 3085A YR-39660
DeviceNet
Overview DeviceNet Flat Media Highlights
DeviceNet Cable Auxiliary Power Cable

User User
CAN_H CAN_L defined 1 defined 2
+24Vdc 0 Vdc +24Vdc 0 Vdc
DeviceNet
Overview
DeviceNet Media
Rockwell sells 5 versions of DeviceNet cable. Three round versions and
2 flat version:
• Round
• Thick – Worldwide generally rated for 8 amps, but the National
Electric Code (NEC) only allows 4 amps for this type of cable in
North America.
• Thin - rated for 3 amps
• Class 1 drop - can only be used for drop cable
• Flat
• Original Heavy Duty KwiklLink: Class 1 (8A@ 24V dc) or Class 2
(4A @ 24 V dc)
• Newer KwikLink General Purpose: Class 2 (4a @ 24V dc)
All types except Class 1 drop can be used for trunk cable
DeviceNet
Overview What is Class 1 and Class 2?
Class 1 installations require that all components of a cable be able to resist voltages in their vicinity of up to 600
Volts. This is especially important when DeviceNet is used in Motor Control Centers. All components, both trunk
cable and drop cable, must be Class 1 rated for the entire system to be Class 1. The only Class 1 rated media that
you can get through Rockwell is KwikLink original trunk cable and Class 1 drop cable assemblies. See pictures
below. Belden sells Class 1 trunk and drop cable, which is not available through Rockwell. See chart at bottom of
page. Up to 8 amps of current can be drawn through KwikLink and Class 1 round trunk or drop cables.
According to NEC regulations (North America Only), Class 2 Installations can only be in the vicinity
of up to 300 Volts, but no higher. Class 2 cable systems can carry no more than 100 Watts. So doing a
calculation of 100 Watts/24 VDC = 4.16 amps of maximum allowable current in a Class 2 cable. The
1787-DNPS power supply is specifically designed to be used on Class 2 cabling systems.
Cable Belden # Class Shield Distance

Grey PVC Trunk 7896A 1 Yes 80% of Normal Trunk (400m @125K)
Grey PVC Trunk 7897A 1 Yes Full Distance (500m @ 125K)
Grey PVC Drop 7900A 1 No Full Drop (6m @ any baud) rate)
DeviceNet
Overview DeviceNet Media
Each version of trunk cable has different specifications in regards to the

maximum length of the trunk, and the total amount of drop cable allowed.
These values change depending on the baud rate being used on the
network.
The total amount of drop cable allowed, referred to as the “Cumulative
drop budget”, is the total amount of drop cable that can be used to
connect devices to the trunk. As stated previously, there is a limit of 20
feet of drop cable for any single node. In addition, there is a limit of the
total amount of drop cable used on the network. Once that limit is
reached, any additional devices must be connected directly to the trunk.
DeviceNet
Overview Drop Cable Example
In the example network below, the red numbers represent the length (in
feet) of the segment of drop cable. For this example, the total amount of
drop cable used is 55 feet. You can compare this to the cumulative drop
budgets listed in the chart on the following page.
0 0
Node Node
5
Node 5 10
10 Node
15
5 5 0 P/S
Node Node
Node Node
Note that the trunk cable was run all the

The total amount of drop cable used to connect these three way to this node. This is how you would
nodes is 25 feet. Note that this is legal because any single have to connect nodes if you run out of
node is no more than 15 feet from the trunk drop cable budget
DeviceNet
Overview
Cable Specs
Data Rates 125 Kbaud 250 Kbaud 500 Kbaud
Trunk Distance for Thin Cable 100m (328 ft) 100m (328 ft) 100m (328 ft)
Trunk Distance for Thick Cable 500m (1640 ft) 250m (820ft) 100m (328 ft)
Trunk Distance for Flat Cable 420m (1378 ft) 200m (656ft) 75m (246 ft)
Max. Drop Length 6.1m (20 ft) 6.1m (20 ft) 6.1m (20 ft)
Cumulative Drop 156m (512 ft) 78m (256 ft) 39m (128 ft)
Number of nodes 64 64 64
DeviceNet
Overview Extending the Cable Distance
Rockwell does not sell repeaters for the DeviceNet network, but other
companies do. The companies that sell these devices refer to them as
“bus extenders”. They can extend either the trunk or drop lines. Since the
bus extender regenerates the signal, you can effectively double the
maximum allowed cable distance on a segment. The extenders do
introduce a short delay into the system (< 1ms).
Refer to the ODVA web page for details.
DeviceNet
Overview
Extending the Trunk or Drop distances
Various Companies make network

extenders for both the trunk and drop
lines, but I like these products from WRC
best. Each unit allows another maximum
length of cable to be added to either the
trunk or drop lines of a network. For
thick, round media, that would mean
another 500 meters per unit. Multiple
units can be used to extend the trunk or
drop even more. This unit can also
convert to fiber optic for outdoor or high
noise areas. The units cost around $300
each and have become very popular.
Note: These units store and repeat,
which means they will ACK packets on
the local network and retransmit them on
the remote network. This will impart a
small network delay of .5ms, along with
the amount of time a retransmit the
packet, when doing performance
calculations.
DeviceNet
Overview Wireless Modems on DeviceNet
These modems act as invisible

wireless connections between the
Device Net networks they are
attached to. They are very useful for
moving machinery, where cable
connections are not feasible. They are
best for line of sight applications
without a lot of building steel
separating them. Matric will be
coming out with a next generation
modem during Summer 2002 which
will have improved radio signal
transmission and reception.
DeviceNet
Overview Choosing Flat Cable
The cable distance specifications are the same for both types of flat
cable. How do I choose which one to use?
The newer KwikLink cable is more flexible and less expensive than the original
heavy duty KwikLink. That makes it the best choice for most applications. Use
the original heavy duty KwikLink for applications that require class 1 cable
(cables that will be run near high voltage). For example, original KwikLink heavy
duty is used in Rockwell’s MCC’s (motor control centers). Newer KwikLink is
rated class 2.
DeviceNet
Overview Connecting to Flat Cable
Connecting to flat cable is different than round cable in that you don’t have
to cut the cable, or have a specific length cable in order to install a tap.
Taps are clamped directly onto the flat cable wherever they are needed.
The conductors in the tap pierce the cable jacket and contact the
conductors in the cable. This allows you to quickly add nodes to a network
without breaking the cable system.
Once the tap is secured to the cable a
device can be plugged in here.
DeviceNet
Overview
Insulation Displacement Connector (IDC)
Four through-holes for

mounting entire assembly Module Top
Flat Wire
“Sealed style”
“Open style”
“Snap-on”
Mechanically-keyed connection
4-wire flat cable
Term. Resistor Two retentive screws for driving
blades through cable
DeviceNet
Overview
Connecting to Flat Cable
How do I choose between the Original (Heavy-Duty) KwikLink and

KwikLink General Purpose Connectors?
The features required in your DeviceNet flat media application will drive the
selection of connector style.There are a variety of feature differences between the
Original KwikLink and KwikLink General Purpose connectors.
The feature set of the Original KwikLink lends itself to more demanding industrial
applications such as those with washdown conditions or those requiring the use
of 600V cable or Class 1 wiring. In addition, the Original KwikLink connectors
provide greater flexibility with exchangeable snap-on interface caps such as
Micro, Open-Style, Mini Pigtail, Terminators, etc.
The feature set of the KwikLink General Purpose connectors aligns with lighter-
duty industrial applications and provides only micro style connectivity.
DeviceNet
Overview
Can the newer KwikLink General Purpose flat cable be used with the
Original KwikLink connectors?
No. The newer flat cable is highly pliable and has been optimized for use with
vampire style connections. It should not be used with IDC style connections
(such as those in the original KwikLink Connector) as it may result in unreliable
operation and lead to application difficulties.
DeviceNet
Overview
Connection Method: What is the difference between vampire and

IDC?
Rockwell Automation/Allen-Bradley utilizes two separate industrialized
technologies to connect to DeviceNet flat media. Both technologies have been
used in commercial applications for many years and have proven extremely
durable and reliable in industrial applications as well.
The Original Heavy-Duty KwikLink connectors utilize insulation
displacement connection (IDC) technology. This technology is based on the
use of multiple sets of “IDC blades” which displace the insulation on two sides of
a conductor, wedging the wire between them to create a gas-tight electrical
connection.
The newer KwikLink General Purpose connectors (and the flat cable base for
ArmorBlock MaXum hardened distributed I/O) utilize vampire technology. This
technology is based upon multiple “vampire blades” resembling triangular teeth,
which create a gas-tight electrical connection by piercing into a conductor along
its axis.
DeviceNet
Overview
DeviceNet Connectors
DeviceNet offers a wide spectrum of taps and connectors for attaching

devices to the network. There are multiple connectors for each of the
different cable types. Some examples are:
• Open style connectors - low cost connectors that allow devices to be
wired into terminals.
• Sealed style connectors - connectors designed to withstand
environmental hazards such as dust and liquids and meet various
industry ratings standards (I.e IP67).
• Multiport taps - taps that allow more than one device to be
connected.
DeviceNet
Overview Connector Fun Facts
• Open style Phoenix connector

selections.
Note: Ordering 1787-PLUG10R gets

a box of 10 of these connectors
• Open style Phoenix, female connector with jack screws, to sealed style
micro male pin connector. Catalog number 1799-DNC5MMS.
DeviceNet
Overview
Connector Fun Facts
• IP67 Rated Bulkhead connectors for bringing sealed media into enclosures
Description Catalog Number
Bulkhead passthru, 5-pin Micro Female to Male 1485A-CXR5-D5
Bulkhead passthru, 5-pin Mini Female to Male 1485A-CXN5-M5
Bulkhead passthru, 4-pin Mini Female to Male 889A-CXN4-M4
• Open style Y adapter
DeviceNet
Overview Typical Open-Style Connections
These taps are used

with flat cable
Trunk Trunk
Droplines
Droplines
Multiport tap
These taps are used with round cable Taps may be mounted in panels or
in junction boxes with cord grips
DeviceNet
Overview DeviceNet - Sealed-Style Media
Tee Taps
Field Installable Trunk line segments

trunk line -molded mini-connectors
connectors
-screw type Drop lines
-crimp type - molded Multiport tap
connectors
- 0 to 20 ft.
- mini or micro IP65/67, NEMA 4/6P
at device
DeviceNet
Overview Thick Cable Components
1485-CG001A-EN-P
DeviceNet
Overview Thin Cable Components
1485-CG001A-EN-P
DeviceNet
Overview Flat Cable Components
1485-CG001A-EN-P
DeviceNet
Overview Question #1
1. DeviceNet has all of the following benefits except...

a) Reduced hardwiring
b) Reduced start-up time
c) Reduced allowable cable distance
d) Reduced down-time
DeviceNet
Overview Answer #1
1. DeviceNet has all of the following benefits except...

a) Reduced hardwiring
b) Reduced start-up time
c) Reduced allowable cable distance
d) Reduced down-time
Explanation: All the others are benefits that DeviceNet provides. Reduced
allowable cable distance is not a benefit. It is not an issue with DeviceNet either,
as DeviceNet actually provides very good allowable cable distances and offer the
ability to expand cable distances by lowering the baud rate. There are also
DeviceNet repeaters available (check the ODVA website).
DeviceNet
2. What is the maximum distance a node can be from the trunk on DeviceNet?
a) 2 ft
b) 20 ft
c) 200 ft
d) 2m
DeviceNet
Overview Answer #2
2. What is the maximum distance a node can be from the trunk on DeviceNet?
a) 2 ft
b) 20 ft
c) 200 ft
d) 2m
Explanation: All nodes must be within 20 ft of the DeviceNet trunk whether they
are connected directly or indirectly.
DeviceNet
3. DeviceNet cables carry 24V DC power.

a) True
b) False
DeviceNet
Overview Answer #3
3. DeviceNet cables carry 24V DC power.

a) True
b) False
Explanation: DeviceNet network provides 24V power for the DeviceNet

transceivers in each node.
DeviceNet
4. If you have a Round Thin cable running at a data rate of 250 Kbaud, what is
the maximum distance of the cable?
a) 1m
b) 10 m
c) 50 m
d) 100 m
DeviceNet
Overview Answer #4
4. If you have a Round Thin cable running at a data rate of 250 Kbaud, what is
the maximum distance of the cable?
a) 1m
b) 10 m
c) 50 m
d) 100 m
Explanation: The answer can be found in the table given for

Round Thin cable.
(Confidential – For Internal Use Only)
Copyright © 2007 Rockwell Automation, Inc. All rights reserved.
51

DNET Overview

Enviado por

Dados do documento

Direitos autorais

Formatos disponíveis

Compartilhar este documento

Compartilhar ou incorporar documento

Opções de compartilhamento

Você considera este documento útil?

Este conteúdo é inapropriado?

Direitos autorais:

Formatos disponíveis

DNET Overview

Enviado por

Direitos autorais:

Formatos disponíveis

DeviceNet

(Confidential – For Internal Use Only)

Copyright © 2007 Rockwell Automation, Inc. All rights reserved.

Gateway or Linking Device

From the Internet to DeviceNet

Control Network Device Network

Smart I/O 24vdc

DeviceNet is a device level industrial network which allows direct

• Selectable data rates: 125, 250, 500 Kbaud

• Owns the DeviceNet technology

Node Node max

Branching Drop Zero Drop Short Drops

DeviceNet allows multiple devices to be connected to a single tap. You

Node Node max

Branching Drop Zero Drop Short Drops

• Termination resistors are 121 Ohms, 1/4 Watt, 1%

Round Cable Flat Cable

Red +24 Vdc White CAN_H

Node Node max

• Characteristics and Advantages

• Characteristics and Advantages

• Single & multiple supply configurations

• 5 Conductors, 1 pair for 24 Volts DC power, 1 pair

Beldfoil Aluminum/Polyester Shield

Thick Cable Belden Class Capacity (DC Amps)

Beldfoil Aluminum/Polyester Shield

Vinyl or CPE Jacket Polypropylene Fillers

DeviceNet Cable Auxiliary Power Cable

Cable Belden # Class Shield Distance

Each version of trunk cable has different specifications in regards to the

Note that the trunk cable was run all the

Data Rates 125 Kbaud 250 Kbaud 500 Kbaud

Refer to the ODVA web page for details.

Various Companies make network

These modems act as invisible

Four through-holes for

How do I choose between the Original (Heavy-Duty) KwikLink and

Connection Method: What is the difference between vampire and

DeviceNet offers a wide spectrum of taps and connectors for attaching

• Open style Phoenix connector

Note: Ordering 1787-PLUG10R gets

Description Catalog Number

Bulkhead passthru, 5-pin Micro Female to Male 1485A-CXR5-D5

Bulkhead passthru, 5-pin Mini Female to Male 1485A-CXN5-M5

Bulkhead passthru, 4-pin Mini Female to Male 889A-CXN4-M4

• Open style Y adapter

These taps are used

Field Installable Trunk line segments

1. DeviceNet has all of the following benefits except...

1. DeviceNet has all of the following benefits except...

3. DeviceNet cables carry 24V DC power.

3. DeviceNet cables carry 24V DC power.

Explanation: DeviceNet network provides 24V power for the DeviceNet

Explanation: The answer can be found in the table given for

Copyright © 2007 Rockwell Automation, Inc. All rights reserved.

Você também pode gostar
